8. Technical Data for Standard Equipment
8.1 Electrical data
mains supply voltage 100 to 250 V AC / 47 to 63 Hz
consumed power 50 W
mains fuse M 2A / 250 V
high-voltage supplies
Positive and negative high voltage is provided by two independent power supplies.
voltage (max.)
current (max.)
positive
6000 V
1000 µA
negative
6000 V
1000 µA
Monitoring of high voltage
voltage (blue socket): 0 - 6000 V = 0 - 10 V
current (red socket): 0 - 1000 µA = 0 - 10 V
8.2 Mechanical data (standard values)
There are two versions of the mechanical part of the CD-2000 with different mixing air
flows:
type A is for air flows from 2 to 18 m³/h
type B is for air flows from 3 to 36 m³/h
inlet:
aerosol:
volume flow:
0 - 4 m³/h
connection:
da = 8 mm; di = 6 mm
mixing air:
cleaned, dry pressurized
air
type A, 'small'
type B, 'big'
volume flow:
2 - 18 m³/h
3 - 36 m³/h
hose coupling for hose:
i 6 mm
a 8 mm
i 13 mm
outlet:
aerosol and charged mixing air
connection:
da = 16 mm
di = 12 mm
