OPERATING MANUAL CD 2000
Palas
®
GmbH, Karlsruhe, Version V002022014
3. Short Operating Instructions
3.1 Connections
Connect mixing air, aerosol inlet and outlet to the discharge chamber
Connect grounding cable of HV-power supply to discharge chamber
Connect high-tension lead to positive/negative outlet of power supply.
Pay attention to polarity!!
Connect power cord to HV-power supply
3.2 Switching-on Procedure
FIRST Deliver mixing air. Adjust volume flow. On this occasion consider the
allowable volume flow range. The mixing air flow must always be bigger
than the aerosol flow at the aerosol inlet.
THEN Switch on the discharge unit.
AT LAST Deliver aerosol.
Thus it is assured that aerosols do not enter the discharge chamber.
3.3 Switching-off Procedure
Follow the switching on procedure in reverse order:
Aerosol off, discharge off, mixing air off.
