ILK 22/33/44/55/66 INSTALLATION MANUAL
Revision 1.6 - 44 -
7.1 Decal Placement and Inspection
For operator’s safety, all decals appearing in “Decal Kit” must be in a conspicuous place on control
side of liftgate to be read by operator. This is typically a combination of decals on the liftgate and
truck body. Please make sure to place the maximum capacity decal (C) on driver and curb side.
IMPORTANT: Never remove or paint over any decal.
(A) 1 ATG-URGWA - Urgent warning: Elevating gate instructions
(B) 1 ATG-ILK - Main Operation (Control Box)
(C) 2 ATG-XXXX - Max. Capacity (please check the serial number plate to find out your specific capacity)
(D) 1 ATG-CAB - Liftgate Shut-Off (must be placed next to the Shut-Off Switch)
(E) 1 ATG-BKR - Circuit Breaker Reset (must be located at the circuit breaker)
(F) 2 ATG-WLH - Warning: liftgate can crush
(G) 2 ATG-CTN - Caution: Always stand clear of platform area
(H) 1 ATG-RESET - Circuit Breaker Protection
(J) 1 ATG-OPENILD - Notice for Open & Close
(K) 1 ATG-FT - Notice for Foot Control (if applicable)
(L) 1 85-0415-000 – Torque Specifications (Bolt On Mount Plates)
