ILK 22/33/44/55/66 INSTALLATION MANUAL
Revision 1.6 - 6 -
3 Button Hand control
Mount frame
Tilt Cylinder
(outside of the Frame)
Lift Arm
Lift Cylinder
Platform
Warning Lights
Center of Gravity of
maximum load
Cart Stops
(optional)
Foot control
(optional)
Platform
sensor B15
(under the
platform)
Rear bumper
Hydraulic Power Unit on
slide tray
(inside the mount frame)
Lift arm sensor
B13
Serial Tag
Control box
Circuit Board
(behind cover)
Gate Overview and Components
