ILK 22/33/44/55/66 INSTALLATION MANUAL
Revision 1.6 - 5 -
Mounting Notes:
Read and clearly understand manual BEFORE beginning ANY work
Important!!!
The basic rule of PALFINGER Liftgates ILK installation is to raise mount frame
to achieve MAXIMUM ground clearance WITHOUT exceeding Min “F” dimension.
Refer to mounting tables and determine the proper [S] dimension. If the sill is greater than what’s allowed,
the sill has to be notched and capped to achieve original strength. Bend flat stock and weld 100% around
the notch.
Warning
• Minimum bed height dimensions are ALWAYS MAXIMUM LOADED TRUCK
• Floor Height Ranges: Max=Unloaded Truck; Min=Loaded
Installing a gate at or close to minimum bed height normally results in a gate that will NOT open and
close from stored position if the minimum floor height is exceeded when truck is loaded.
Call tech support before starting the installation if you have any questions or concerns
on mounting dimensions → 888-774-5844
