palintest Lumiso Pooltest 6 User Manual

45
Technical Specification
Instrument Dual wavelength, direct-reading
colorimeter
Optics Palintest dual LED light source optical
system with narrow band wavelength
filters and photodetectors
Wavelengths Automatic wavelength selection
of 530 nm or 575 nm
Wavelength
Tolerance
± 2 nm
Filter Bandwidth 5 nm
LCD Display 226 x 138 pixel with adjustable backlight
Instrument
Operating
Conditions
0 – 50°C
90% Relative Humidity (non-condensing)
Waterproof Rating IP67 (Waterproof)
Test Cells 25 mm diameter tubes
Blank/Zero setting Held in memory, but to maintain test
accuracy, instrument will prompt for
re-blanking after 50 minutes or if
environmental temperature has changed.
Power Supply 3 x 1.5V AA batteries
USB Port 6V max, 200mA max (DC)
USB Port Micro USB Type B
Size 163 x 70 x 45 mm
Weight 275g (including batteries)
