Section 1: Pall PCM500 and PCM500W Fluid
Cleanliness Monitors
Specification and Requirements
1.1 General Description
The Pall PCM500/PCM500W is specifically developed as a portable diagnostic
monitoring device that provides an assessment of system fluid cleanliness. A fixed
display/controller allows for simple menu driven input of sample identification, monitor
configuration and data output in ISO4406, SAE AS 4059 Table 1 (NAS 1638) or SAE
AS 4059 Table 2 formats. The display/controller shows the test results, an option to
graph results and this data is automatically stored for subsequent trending and
evaluation. The self-contained design provides for a portable fluid contamination
monitor that can be used with a range of fluids including mineral oils and aqueous
solutions. Note: The PCM500W should not be used for aqueous solutions.
Fluid change procedures are included in this manual and these help to ensure the
PCM500 monitor is adequately flushed ready for an alternative fluid application
See Pall Datasheet M&EPCM500EN for full technical specification
The full technical specification is given below.
1.2 Fluid Environment
Operating Pressure range 0 to 315 bar (4,570 psi) maximum
Operating Viscosity range 1.5 to 450 Centistokes (30 to 2,200 SUS)
Operating System Mineral Oils 10C - 80ºC (50°F - 176°F)
Temperature Water Glycols 10ºC - 60ºC (50°F - 140°F)
Water Based Fluid 10ºC - 60ºC (50°F - 140°F)
Fuels 10ºC - 40ºC (50°F - 104°F)
Industrial Phosphate
Esters & Polyesters 10ºC - 80ºC (50°F - 176°F)
Be aware of possible danger associated with high oil temperatures and
exposed metal surfaces of the PCM500
Fluid Compatibility
Aqueous solutions having a pH <11.0, water glycols, high water based
fluids, petroleum based fluids, industrial phosphate esters, mineral oils
and synthetic fluids.
Do not use Acetone based fluid.
Seals Fluorocarbon (Viton)
WARNING: Health and Safety.
Observe caution when handling fluids and pay attention to instructions of
safe use in the Material Safety Data sheet and COSHH regulations.
Wear protective clothing if prescribed; e.g. safety gloves, clothing and
footwear.
Caution: Health and Safety.
Ensure there is adequate lighting to operate the equipment.
Observe local regulations for factory use.
7
