8
INSTALLATION INSTRUCTIONS
A. Insert the latch into the latch hole. Using the faceplate as a pattern, TRACE a line along the out
edge of the faceplate and chisel a 4mm (1/8") slot in the marked out area. Face plate should fit
flush with door edge.
B. Insert the latch into the latch hole and fasten with screws.
Show pencil marking outer edge of latch faceplate with Dotted lined
directional arrows as you do not just carve out the screw holes
A B
3. LATCH INSTALLATION
