22
INSTALLATION INSTRUCTIONS
A. Insert the key horizontally and turn counter-clockwise 90 degrees.
B. Insert the catch tool into the access hole on the lever. Once the lever is released, remove the
catch tool and pull the lever off.
NOTE: This step is required if you are rekeying the lock.
A
B
8-3. EXCHANGE OF LEVER (REMOVAL OF OUTSIDE LEVER)
