Panasonic ABJ - Page 2

ABJ1,2,3,4,5
With Agency standard type
CONTACT ARRANGEMENT
APPLICABLE CURRENT RANGE (reference)
Type of
switch
ABJ:
Turquoise
switch
J type
Size of
mounting hole
1:
2:
3:
1.2 mm
2.3 mm
3 mm
Ter minal
4:
5:
6:
Solder terminal
PC board terminal
Wire leads
(bottom type)
Contact
arrangement
1:
2:
3:
SPDT
SPST-NC
(Wire leads
type only)
SPST-NO
(Wire leads
type only)
Actuator
0:
2:
4:
6:
8:
Pin plunger
Hinge lever
Simulated roller lever
Roller lever
Leaf lever
(Mounting hole 3 mm
lead wire type only)
Operating force by
pin plunger (max.)
4:
6:
1.23 N
1.96 N
Contact
0:
1:
AgNi alloy
AgNi alloy
+ Au clad
Agency
standard
9: UL/CSA
6 × 10
3
rated
Ex. ABJ 1 4 1 0 4 0 9
Remarks: 1. Standard packing: Dust protected type 100 pcs./carton, 2,000 pcs./case; Immersion protected type 50 pcs./case.
2. Not every combination is available. Please refer to the following table, “PRODUCT TYPES”.
1. SPDT 2. SPST-NC (Wire leads type only) 3. SPST-NO (Wire leads type only)
COM NO NC COM NC COM NO
AgNi alloy
Note) OF: Value of pin plunger
1mA
100mA
1A
2A
0
30V
125V
5V
5V
15V
15V
DC
AC
OF1.23N OF1.96N
Au clad
