Panasonic ABJ - Product Types

ABJ1,2,3,4,5
PRODUCT TYPES
1. Dust protected type (Terminal type)
Mounting hole 1.2mm type / Mounting hole 2.3mm type
AgNi alloy
AgNi alloy + Au clad
2-(1). Immersion protected type (Bottom wire leads type)
Mounting hole 1.2mm type
AgNi alloy
Mounting hole 2.3mm type
AgNi alloy + Au clad
Actuator
Operating force
Max.
Mounting hole 1.2 mm type Mounting hole 2.3 mm type
Solder terminal PC board terminal Solder terminal
Pin plunger
1.23 N ABJ1410409 ABJ1510409 ABJ2410409
1.96 N ABJ1410609 ABJ1510609 ABJ2410609
Hinge lever
0.39 N ABJ1412409 ABJ1512409 ABJ2412409
0.64 N ABJ1412609 ABJ1512609 ABJ2412609
Simulated roller lever
0.39 N ABJ1414409 ABJ1514409 ABJ2414409
0.64 N ABJ1414609 ABJ1514609 ABJ2414609
Roller lever
0.39 N ABJ1416409 ABJ1516409 ABJ2416409
0.64 N ABJ1416609 ABJ1516609 ABJ2416609
Actuator
Operating force
Max.
Mounting hole 1.2 mm type Mounting hole 2.3 mm type
Solder terminal PC board terminal Solder terminal
Pin plunger
1.23 N ABJ1410419 ABJ1510419 ABJ2410419
1.96 N ABJ1410619 ABJ1510619 ABJ2410619
Hinge lever
0.39 N ABJ1412419 ABJ1512419 ABJ2412419
0.64 N ABJ1412619 ABJ1512619 ABJ2412619
Simulated roller lever
0.39 N ABJ1414419 ABJ1514419 ABJ2414419
0.64 N ABJ1414619 ABJ1514619 ABJ2414619
Roller lever
0.39 N ABJ1416419 ABJ1516419 ABJ2416419
0.64 N ABJ1416619 ABJ1516619 ABJ2416619
Actuator
Operating force
Max.
Mounting hole 1.2 mm type
SPDT SPST-NC SPST-NO
Pin plunger
1.23 N ABJ1610409 ABJ1620409 ABJ1630409
1.96 N ABJ1610609 ABJ1620609 ABJ1630609
Hinge lever
0.39 N ABJ1612409 ABJ1622409 ABJ1632409
0.64 N ABJ1612609 ABJ1622609 ABJ1632609
Simulated roller lever
0.39 N ABJ1614409 ABJ1624409 ABJ1634409
0.64 N ABJ1614609 ABJ1624609 ABJ1634609
Roller lever
0.39 N ABJ1616409 ABJ1626409 ABJ1636409
0.64 N ABJ1616609 ABJ1626609 ABJ1636609
Actuator
Operating force
Max.
Mounting hole 1.2 mm type
SPDT SPST-NC SPST-NO
Pin plunger
1.23 N ABJ1610419 ABJ1620419 ABJ1630419
1.96 N ABJ1610619 ABJ1620619 ABJ1630619
Hinge lever
0.39 N ABJ1612419 ABJ1622419 ABJ1632419
0.64 N ABJ1612619 ABJ1622619 ABJ1632619
Simulated roller lever
0.39 N ABJ1614419 ABJ1624419 ABJ1634419
0.64 N ABJ1614619 ABJ1624619 ABJ1634619
Roller lever
0.39 N ABJ1616419 ABJ1626419 ABJ1636419
0.64 N ABJ1616619 ABJ1626619 ABJ1636619
