Panasonic ABJ - Page 4

ABJ1,2,3,4,5
Mounting hole 2.3mm type
AgNi alloy
AgNi alloy + Au clad
Mounting hole 3mm type (Leaf lever type)
AgNi alloy
AgNi alloy + Au clad
2-(2). Immersion protected type (Side wire leads type)
Fixed pin (right side pin) type
AgNi alloy
AgNi alloy + Au clad
Actuator
Operating force
Max.
Mounting hole 2.3 mm type
SPDT SPST-NC SPST-NO
Pin plunger
1.23 N ABJ2610409 ABJ2620409 ABJ2630409
1.96 N ABJ2610609 ABJ2620609 ABJ2630609
Hinge lever
0.39 N ABJ2612409 ABJ2622409 ABJ2632409
0.64 N ABJ2612609 ABJ2622609 ABJ2632609
Simulated roller lever
0.39 N ABJ2614409 ABJ2624409 ABJ2634409
0.64 N ABJ2614609 ABJ2624609 ABJ2634609
Roller lever
0.39 N ABJ2616409 ABJ2626409 ABJ2636409
0.64 N ABJ2616609 ABJ2626609 ABJ2636609
Actuator
Operating force
Max.
Mounting hole 2.3 mm type
SPDT SPST-NC SPST-NO
Pin plunger
1.23 N ABJ2610419 ABJ2620419 ABJ2630419
1.96 N ABJ2610619 ABJ2620619 ABJ2630619
Hinge lever
0.39 N ABJ2612419 ABJ2622419 ABJ2632419
0.64 N ABJ2612619 ABJ2622619 ABJ2632619
Simulated roller lever
0.39 N ABJ2614419 ABJ2622419 ABJ2634419
0.64 N ABJ2614619 ABJ2624619 ABJ2634619
Roller lever
0.39 N ABJ2616419 ABJ2626419 ABJ2636419
0.64 N ABJ2616619 ABJ2626619 ABJ2636619
Actuator
Operating force
Max.
Mounting hole 3 mm type
SPDT SPST-NC SPST-NO
Leaf lever
0.98 N ABJ3618409 ABJ3628409 ABJ3638409
1.27 N ABJ3618609 ABJ3628609 ABJ3638609
Actuator
Operating force
Max.
Mounting hole 3 mm type
SPDT SPST-NC SPST-NO
Leaf lever
0.98 N ABJ3618419 ABJ3628419 ABJ3638419
1.27 N ABJ3618619 ABJ3628619 ABJ3638619
Actuator
Operating force
Max.
Wire leads direction
Wire leads type
SPST-NC SPST-NO
Leaf lever
1.27 N Right ABJ472840 ABJ473840
1.27 N Left ABJ482840 —
1.76 N Right ABJ472860 ABJ473860
1.76 N Left ABJ482860 —
Actuator
Operating force
Max.
Wire leads direction
Wire leads type
SPST-NC SPST-NO
Leaf lever
1.27 N Right ABJ472841 ABJ473841
1.27 N Left ABJ482841 —
1.76 N Right ABJ472861 ABJ473861
1.76 N Left ABJ482861 —
