Panasonic ABJ - Specifications

ABJ1,2,3,4,5
Fixed pin (left side pin) type
AgNi alloy
AgNi alloy + Au clad
Mounting hole 3mm type
AgNi alloy
AgNi alloy + Au clad
3. Immersion protected type (Bottom wire leads type) Long stroke type
Mounting hole 2.3mm type
AgNi alloy
AgNi alloy + Au clad
SPECIFICATIONS
1. Contact rating
Actuator
Operating force
Max.
Wire leads direction
Wire leads type
SPST-NC SPST-NO
Leaf lever
1.27 N Right ABJ572840 ABJ573840
1.27 N Left ABJ582840 —
1.76 N Right ABJ572860 ABJ573860
1.76 N Left ABJ582860 —
Actuator
Operating force
Max.
Wire leads direction
Wire leads type
SPST-NC SPST-NO
Leaf lever
1.27 N Right ABJ572841 ABJ573841
1.27 N Left ABJ582841 —
1.76 N Right ABJ572861 ABJ573861
1.76 N Left ABJ582861 —
Actuator
Operating force
Max.
Wire leads direction
Wire leads type
SPST-NC
Leaf lever
1.27 N
Left
ABJ382840
1.76 N ABJ382860
Actuator
Operating force
Max.
Wire leads direction
Wire leads type
SPST-NC
Leaf lever
1.27 N
Left
ABJ382841
1.76 N ABJ382861
Actuator
Operating force
Max.
Mounting hole 2.3 mm type
SPDT SPST-NC SPST-NO
Pin plunger (Horizontal) 2.45 N *ABJ261L70 ABJ262L70 ABJ263L70
Actuator
Operating force
Max.
Mounting hole 2.3 mm type
SPDT SPST-NC SPST-NO
Pin plunger (Horizontal) 2.45 N *ABJ261L71 ABJ262L71 ABJ263L71
Type Operating force Max. Standard rating Low-level circuit rating
AgNi alloy contact
1.76 N, 1.96 N
2 A 125 V AC
2 A 30 V DC
—
1.23 N, 1.27 N
1 A 125 V AC
1 A 30 V DC
—
Long stroke type
AgNi alloy contact
2.45 N
1 A 125 V AC
1 A 30 V DC
—
AgNi alloy + Au clad contact
1.23 N, 1.27 N
1.76 N, 1.96 N
0.1 A 125 V AC
5 mA 6 V DC
2 mA 12 V DC
1 mA 24 V DC
Long stroke type
AgNi alloy + Au clad contact
2.45 N
0.1 A 125 V AC
0.1 A 30 V DC
5 mA 6 V DC
2 mA 12 V DC
1 mA 24 V DC
