Panasonic AG-CX7

Chapter 7 Output and Screen Display — Output format
- 156 -
Output format
The format to be output differs depending on the setting in the [SYSTEM] menu → [FREQUENCY]/[REC FORMAT].
Format that can be output from the <SDI OUT> terminal [CX8]/[CX10]
The format that can be output from the <SDI OUT> terminal differs with following combination of the settings.
≥ [SYSTEM] menu → [FREQUENCY]
≥ [SYSTEM] menu → [REC FORMAT]
≥ [VIDEO OUT/LCD/VF] menu → [SDI OUT] → [OUT FORMAT]
* Factory setting
@
NOTE
0 The 3840×2160 output is not supported.
0 User bits are not displayed.
0 [OUT FORMAT] restores the factory settings when the settings of [FREQUENCY] and [REC FORMAT] change and the current setting values of [OUT
FORMAT] cannot be acquired.
0 The output format when playing back from the thumbnail screen is as follows.
j It will be the value set in [OUT FORMAT] when the recording resolution of the playback clip is the same as [REC FORMAT].
j It will be factory setting of [OUT FORMAT] when the recording resolution of the playback clip is different from [REC FORMAT].
0 There may be a fews seconds of images not displayed on the external device when the clips are changing over, etc.
Item
[OUT FORMAT]: Output Format
[FREQUENCY]
[REC FORMAT]
Resolution Frame rate
[59.94Hz] 3840×2160 59.94p [1920×1080p]:
[1920×1080i]
*
:
1920×1080/59.94p 4:2:2 10 bit
1920×1080/59.94i 4:2:2 10 bit
29.97p [1920×1080p]:
[1920×1080PsF]
*
:
1920×1080/29.97p 4:2:2 10 bit
1920×1080/29.97PsF 4:2:2 10 bit
23.98p [1920×1080p]:
[1920×1080PsF]
*
:
1920×1080/23.98p 4:2:2 10 bit
1920×1080/23.98PsF 4:2:2 10 bit
1920×1080 59.94p [1920×1080p]:
[1920×1080i]
*
:
1920×1080/59.94p 4:2:2 10 bit
1920×1080/59.94i 4:2:2 10 bit
59.94i [1920×1080i]: 1920×1080/59.94i 4:2:2 10 bit
29.97p [1920×1080p]:
[1920×1080PsF]
*
:
1920×1080/29.97p 4:2:2 10 bit
1920×1080/29.97PsF 4:2:2 10 bit
23.98p [1920×1080p]:
[1920×1080PsF]
*
:
1920×1080/23.98p 4:2:2 10 bit
1920×1080/23.98PsF 4:2:2 10 bit
1280×720 59.94p [1280×720p]: 1280×720/59.94p 4:2:2 10 bit
[50.00Hz] 3840×2160 50.00p [1920×1080p]:
[1920×1080i]
*
:
1920×1080/50.00p 4:2:2 10 bit
1920×1080/50.00i 4:2:2 10 bit
25.00p [1920×1080p]:
[1920×1080PsF]
*
:
1920×1080/25.00p 4:2:2 10 bit
1920×1080/25.00PsF 4:2:2 10 bit
1920×1080 50.00p [1920×1080p]:
[1920×1080i]
*
:
1920×1080/50.00p 4:2:2 10 bit
1920×1080/50.00i 4:2:2 10 bit
50.00i [1920×1080i]: 1920×1080/50.00i 4:2:2 10 bit
25.00p [1920×1080p]:
[1920×1080PsF]
*
:
1920×1080/25.00p 4:2:2 10 bit
1920×1080/25.00PsF 4:2:2 10 bit
1280×720 50.00p [1280×720p]: 1280×720/50.00p 4:2:2 10 bit
