94
Setup Menu: Menu List
_ is the factory default setting.
AUDIO
Item Settings and brief function description FREQ indications
INPUT SEL
Selects the audio input signal.
SDI
: Selects the SDI connector.
ANALOG: Selects the ANALOG AUDIO IN connector.
AES/EBU: Selects the AES/EBU connector.
INT SG: Selects the internal signal generator.
INPUT CH1 LEVEL
Selects the level for the CH1 analog audio input.
4 dB
0 dB
-3 dB
-20 dB
INPUT CH2 LEVEL
Selects the level for the CH2 analog audio input.
4 dB
0 dB
-3 dB
-20 dB
RATE CONV.
Records and plays without passing the video through the rate converter (without applying a
digital filter) during digital audio input/output.
ON
: Records and plays while passing the data through the rate converter.
OFF: Records and plays without passing the data through the rate converter.
Note:
• The on/off of all recording and playback channels is controlled simultaneously. It cannot
be set for each channel separately.
• When the rate converter is off, the video input and digital audio input need to be syn-
chronized. The video input and the reference signal selected in “OUTPUT REF” (➝ page
106) also need to be synchronized. (If they are not synchronized, noise may be output.)
OUTPUT CH1/L
LEVEL
Selects the level for the CH1/L analog audio output.
4 dB
0 dB
-3 dB
-20 dB
OUTPUT CH2/R
LEVEL
Selects the level for the CH2/R analog audio output.
4 dB
0 dB
-3 dB
-20 dB
OUTPUT
EMBD(SD) CH
Selects the channels to multiplex on the SD SDI output.
OFF: Does not superimpose.
CH1-4
: Outputs the four channels CH1-4.
CH5-8: Outputs the four channels CH5-8.
CH1-8: Outputs the eight channels CH1-8.
Note:
• The four channels CH1-4 are always multiplexed during DV, DVCPRO, and DVCPRO50
playback.
• Some devices may not be able to receive eight channels. Check the specifications of
the receiving device before setting CH1-8.
OUTPUT
EMBD(HD) CH
Selects the channels to multiplex on the HD SDI output.
OFF: Does not superimpose.
CH1-8
: Outputs the eight channels CH1-8.
Note:
Channels not included in a playback clip are output as no sound.
OUTPUT AES/EBU
CH
Sets the channels to output to AES/EBU.
CH1-4
: Outputs the four channels CH1-4.
CH5-8: Outputs the four channels CH5-8.
Note:
Channels not included in a playback clip are output as no sound.
To Next Page
