Connector signals
VIDEO IN
SDI IN
(DIGITAL)
BNCa2, Active through
Y, PB, PR
(ANALOG)
BNCa3 (Board, option)
VIDEO IN
BNCa2, Loop-through,
75Ω termination switch provided (Board, option)
REF VIDEO IN
BNCa2, Loop-through,
75Ω termination switch provided
AUDIO IN
SDI IN
(DIGITAL)
BNCa2, Active through
AUDIO IN
(DIGITAL)
BNCa2 (CH1/CH2, CH3/CH4)
AES/EBU format
AUDIO IN
(ANALOG)
XLRa4 (CH1, CH2, CH3, CH4)
TIME CODE
IN
XLRa1
AUDIO OUT
SDI OUT
(DIGITAL)
BNCa3
AUDIO OUT
(DIGITAL)
BNCa2 (CH1/CH2, CH3/CH4)
AES/EBU format
AUDIO OUT
(ANALOG)
XLRa4 (CH1, CH2, CH3, CH4)
TIME CODE
OUT
XLRa1
MONITOR
OUT
XLRa2 (L/R)
HEADPHONES
(front)
Stereo mini jack
RS-422A REMOTE (9P)
O REMOTE IN/OUT
VIDEO OUT
SDI OUT
(DIGITAL)
BNCa3
Y, PB, PR
(ANALOG)
BNCa3
VIDEO OUT
BNCa3
Pin No. Signal
1 FRAME GROUND
2 TRANSMIT A
3 RECEIVE B
4 RECEIVE COMMON
5
====
6 TRANSMIT COMMON
7 TRANSMIT B
8 RECEIVE A
9 FRAME GROUND
O REMOTE OUT
Pin No. Signal
1 FRAME GROUND
2 RECEIVE A
3 TRANSMIT B
4 TRANSMIT COMMON
5
====
6 RECEIVE COMMON
7 RECEIVE B
8 TRANSMIT A
9 FRAME GROUND
