Panasonic AJ-SDX900p - Chapter 7 Menu description tables; 7-8 VTR MENU; 7-8-5 MIC;AUDIO1

97
7
Chapter 7 Menu description tables
7-8-5 MIC/AUDIO1
TEST TONE NORMAL
ALWAYS
OFF
CHSEL
For selecting the test signal.
NORMAL: The test tone signal is output to all
the channels when the CAM/BAR
switch has been set to BAR and the
CH1 AUDIO IN switch has been set
to FRONT.
ALWAYS: The test tone signal is always output
to all the channels when the CAM/
BAR switch has been set to BAR.
OFF: The test tone signal is not output.
CHSEL: The test tone signal is output to the
channels for which the CH1 or CH2
AUDIO IN switch has been set to
FRONT when the CAM/BAR switch
is set to BAR. It is not output to CH3
or CH4.
Item
Variable
range
Remarks
FRONT VR CH1 FRONT
W.L.
REAR
ALL
OFF
For setting whether or not to make the audio
control operational for the input system
selected for CH1.
FRONT VR CH2 FRONT
W.L. REAR
ALL
OFF
For setting whether or not to make the audio
control operational for the input system
selected for CH2.
MIC LOWCUT CH1 FRONT
REAR
W.L.
OFF
For selecting the microphone low-cut filter for
CH1.
MIC LOWCUT CH2 FRONT
REAR
W.L.
OFF
For selecting the microphone low-cut filter for
CH2.
MIC LOWCUT CH3 FRONT
REAR
W.L.
OFF
For selecting the microphone low-cut filter for
CH3.
MIC LOWCUT CH4 FRONT
REAR
W.L.
OFF
For selecting the microphone low-cut filter for
CH4.
LIMITER CH1 ON
OFF
For selecting the limiter for CH1.
LIMITER CH2 ON
OFF
For selecting the limiter for CH2.
AUTO LEVEL CH3 ON
OFF
For selecting the method used to set the level.
AUTO LEVEL CH4 ON
OFF
For selecting the method used to set the level.
REC CH3/CH4 SW
CH1/2
For selecting the signals to be recorded for
CH3 and CH4.
SW:
The signals complying with the
position of the CH3/CH4 selector
switch on the side panel are recorded.
CH1&2: The same signals for CH1 and CH2
are recorded for CH3 and CH4. The
CH3&4 input circuit is set to the
power-saving mode.
CUE REC SELECT CH1
CH2
CH3
CH4
CH1+CH2
CH3+CH4
For selecting the signals to be recorded for
the CUE channel.
TYPE A
¢
/
11.0
:
13.5
:
15.0
12.0
:
15.0
:
17.0
For enabling or disabling the selection made
for the BATTERY SELECT item.
¢: The selection is enabled.
/: The selection is disabled.
For selecting in 0.1 V steps the voltage at
which the battery charge is to be considered
nearly depleted.
For selecting in 0.1 V steps the voltage at
which FULL is to be displayed.
11.0
:
11.9
:
15.0
For selecting in 0.1 V steps the voltage at
which the battery charge is to be considered
depleted.
Item
Variable
range
Remarks
TYPE B
¢
/
11.0
:
13.1
:
15.0
12.0
:
15.5
:
17.0
For enabling or disabling the selection made
for the BATTERY SELECT item.
¢: The selection is enabled.
/: The selection is disabled.
For selecting in 0.1 V steps the voltage at
which the battery charge is to be considered
nearly depleted.
For selecting in 0.1 V steps the voltage at
which FULL is to be displayed.
11.0
:
12.6
:
15.0
For selecting in 0.1 V steps the voltage at
which the battery charge is to be considered
depleted.
NEAR END
FULL
END
NEAR END
FULL
END
