16
The following describes [ROP MENU] settings.
＊＊ ＳＨＡＤＩＮＧ（ ＷＨＩＴＥ ） ＊＊
ＷＨＩＴＥ ＳＨＡＤＩＮＧ ＳＷＩＴＣＨ
→
Ｇ
Ｂ
Ｒ
ＨＳＡＷ ＨＰＡＲＡ ＶＳＡＷ ＶＰＡＲＡ
ＯＮ
０ ０ ０ ０
０ ０ ０ ０
０ ０ ０ ０
( indicates factory default settings.)
Enables/disables white shading.
Performs sawtooth wave
correction of white screen
images in the horizontal
direction.
Performs parabola correction
of white screen images in the
horizontal direction.
Performs sawtooth wave
correction of white screen
images in the vertical direction.
Performs parabola correction
of white screen images in the
vertical direction.
→
＊＊ ＰＥＤＥＳＴＡＬ／ＦＬＡＲＥ／ＧＡＩＮ ＊＊
ＦＬＡＲＥ ＳＷＩＴＣＨ
ＦＬＡＲＥ
ＧＡＩＮ
ＭＡＳＴＥＲ ＰＥＤＥＳＴＡＬ
ＰＥＤＥＳＴＡＬ
Ｒ Ｇ Ｂ
ＯＮ
０ ０ ０
０
０
０
００
０
( indicates factory default settings.)
Set to On to adjust flare
correction amount.
Flare correction controls the
increase in pedestal level in
proportion to light intensity.
Indicates set master pedestal
value. (Settings cannot be
made.)
Amount by which the level is
increased or decreased relative
to the G pedestal to adjust the
black balance. When the auto
black balance is achieved, 0 is
set as the adjustment value.
Adjusts the amount of G
pedestal offset from master
pedestal.
Amount by which the level is
increased or decreased relative
to the G pedestal to adjust the
black balance. When the auto
black balance is achieved, 0 is
set as the adjustment value.
Adjusts the amount of R FLARE
correction.
Adjusts the amount of G FLARE
correction
Adjusts the amount of B FLARE
correction
Adjusts the white balance.
Amount by which the R gain has
to be increased or decreased
relative to the G gain level.
When the auto white balance
is achieved, 0 is set as the
adjustment value.
Adjusts the white balance.
Amount by which the B gain has
to be increased or decreased
relative to the G gain level.
When auto white balance
is achieved, 0 is set as the
adjustment value.
