Panasonic AW-UE20KE - User Manual

Panasonic AW-UE20KE
126 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
DVQP2657YA
W0222AM1042 -AV-PS
ENGLISH
Model No.
  AW-UE20KP
Model No.
  AW-UE20WP
Model No.
  AW-UE20KE
Model No.
  AW-UE20WE
Model No.
  AW-UE20KED
Model No.
  AW-UE20WED
Operating Instruction
Operations and Settings
4K Integrated Camera
Operations and Settings
Operating Instructions
This "Operations and Settings" describes how to operate the unit and how to
establish its settings.
For more information on how to perform basic operation and installation, refer to
the Operating Instructions "Basics".

Table of Contents

Other manuals for Panasonic AW-UE20KE

Preview: Operating Instructions
Operating Instructions96 pages

Questions and Answers

  • M
    Megan MurphyAug 8, 2025
    Why Panasonic AW-UE20KE Digital Camera has no power?
    • E
      Elizabeth ChanAug 8, 2025
      First, ensure the AC adapter is securely connected to the AC outlet and that the power plug of the AC adapter is properly connected. If using PoE+ (IEEE802.3at), verify the network cable is correctly connected. Note that power may not be supplied if the total power limit is exceeded on power supply devices with multiple PoE+ terminals. Also, if connected to a controller, check that the unit is properly connected. For controller details, consult its operating instructions.
  • C
    carrollalanAug 13, 2025
    What to do if Panasonic AW-UE20KE Digital Camera cannot operate using the wireless remote control?
    • K
      Kevin PatelAug 13, 2025
      If the status display lamp doesn't blink when operating the remote near the signal light-sensing area, the batteries may be depleted; replace them. Ensure the Wireless ID is correctly set. Also, check if a fluorescent light or plasma monitor is interfering with the signal. Finally, verify that wireless control is not set to 'Off' in the web screen menu; a rapidly flashing orange power status indicator (5Hz) indicates it is.
  • C
    cathyrussellAug 18, 2025
    How to fix Panasonic AW-UE20KE that cannot operate (common to wireless remote control, controller)?
    • U
      ucareyAug 18, 2025
      First, check if the power is on. If the unit’s status display lamp is off or lights up orange, it means that the unit’s power is not on. Also, verify that the specific unit you're trying to control is correctly selected.
  • J
    Jacob HollandAug 22, 2025
    What to do if Panasonic AW-UE20KE unit turns in the opposite direction?
    • S
      Stacy SchmidtAug 22, 2025
      Ensure that the 'Install Position' setting has been correctly configured. If the unit is connected to a controller, the reversal setting might have been established there; refer to the controller's operating instructions for further details.
  • E
    Emily BurnettAug 28, 2025
    Why Panasonic AW-UE20KE cannot access from a web browser?
    • A
      anitawhiteAug 28, 2025
      Ensure a LAN cable of category 5e or above is connected to the LAN connector for IP control. Check if the [LINK] LED of the LAN connector is lit; if not, there may be a connection issue or network problem. Also, verify that the unit is powered on; if the status display lamp is off or orange, the unit is not on.
  • R
    Richard MartinSep 1, 2025
    What to do if Panasonic Digital Camera cannot operate using the controller?
    • H
      Heather ShermanSep 1, 2025
      Ensure the unit is properly connected to the controller. It might be necessary to upgrade the controller's version to support the unit. For upgrade details, visit the support page on the Panasonic website: https://pro-av.panasonic.net/

Summary

Operating Instruction

Operations and Settings Overview

Describes how to operate the unit and establish its settings.

4 K Integrated Camera

Identifies the product as a 4K Integrated Camera model.

Important Safety Information

Initial Safety Warnings

Provides initial warnings regarding electrical shock and equipment handling.

AC Mains Lead Safety

Getting Started and Network Setup

Required Personal Computer Environment

Network Security Measures

Provides guidelines for securing the unit on a network.

Network Settings Configuration

Guides on setting up network parameters using Easy IP software.

Initial Account Setup

Procedure for setting the initial user account and password.

Camera Characteristics and Operations

Operating Precautions

Important guidelines for proper unit operation and maintenance.

Parts and Functions Overview

Basic Shooting and Menu Operations

Basic Shooting Procedure

Power Management

Instructions for powering the camera unit on and off.

Priority Mode Configuration

Setting the priority mode for video output applications.

Scene Mode Selection

Camera Control and Settings

Picture Direction and Zoom Control

Troubleshooting Basic Shooting

Solutions for common problems encountered during basic shooting.

White Balance Adjustment

System and Maintenance Settings

System Menu: Priority Mode

Configuring the priority output mode for video signals.

Frequency and Format Settings

Maintenance Menu Overview

Default Reset and Initialization

Web Interface Operations

Web Screen Start-up

Connecting to the unit's web interface via PC.

Switching Between Live and Setup Screens

Navigating between the live video feed and setup menus.

Web Live Screen Controls

Operating the camera and managing settings via the web interface.

Basic Web Settings

Configuring basic settings like Priority Mode and Date/Time.

IP Streaming and Audio Configuration

Video over IP Settings

Configuring image settings for IP streaming (JPEG).

H.264;H.265 IP Streaming

Configuring image settings for H.264/H.265 IP streaming.

Audio Settings Configuration

Image Adjustment and Webcam Functions

Image Adjust Dialog

Preset Position Management

Web Camera Functionality

Troubleshooting Guides

Operation Problems Troubleshooting

Web Browser Access Troubleshooting

Video Display Troubleshooting

IP Image and USB Connection Troubleshooting

Panasonic AW-UE20KE Specifications

General IconGeneral
Camera TypePTZ Camera
Effective Pixels12.4 Megapixels
Video OutputHDMI, 3G-SDI, IP
Zoom20x Optical Zoom
Pan Range±175°
Tilt Range-30° to +90°
Image Sensor1/2.5-type MOS
Horizontal ResolutionUp to 1000 TV lines
Network InterfaceEthernet (RJ-45)
Power SupplyDC 12V
Video Format3840 x 2160, 1920 x 1080
IP ProtocolRTSP, RTMP
Shutter Speed1/30 to 1/10000
GainAuto/Manual
White BalanceAuto/Manual
Audio Input3.5 mm mini-jack
Operating Temperature0°C to 40°C
