Description of Parts
Getting StartedUseful InformationTroubleshootingAppendix
A : Hard disk drive
Î Reference Manual “Hard Disk Drive”
B : Smart Card slot
<Only for model with Smart Card slot>
Î Reference Manual “Smart Card”
C : ExpressCard slot
Î Reference Manual “PC Card / ExpressCard”
D :PC Card slot
Î Reference Manual “PC Card / ExpressCard”
E : IEEE 1394 interface connector
Î Reference Manual “IEEE 1394 Devices”
F : USB port
Î Reference Manual “USB Devices”
G : DC-IN jack
H : External display port
Î Reference Manual “External Display”
I : Security lock
A Kensington cable can be connected.
For further information, read the manual that comes
with the cable.
J : Ventilation hole
K : SIM Card slot
<For Wireless WAN model>
When the SIM Card is necessary, remove the screw of
the cover and then remove the cover to insert/remove
the SIM Card.
L : Modem port
Î Reference Manual “Modem”
M : LAN port
Î Reference Manual “LAN”
N : Serial port
O : Expansion bus connector
Î Reference Manual “Port Replicator”
P : RAM module slot
Î Reference Manual “RAM Module”
Q : Hard disk drive latch
Î Reference Manual “Hard Disk Drive”
R : Multimedia pocket release button
Î Reference Manual “Multimedia Pocket”
S : Battery latch
NOTE
z When you open the covers
of ExpressCard slot, PC
card slot, IEEE 1394
interface connector, USB
port, External display port,
Modem port, LAN port and
Serial port, push down and
pull the covers.
z This computer contains a
magnet and magnetic
products at the locations
circled in the illustration
at right. Avoid leaving
metallic object or mag-
netic media in contact
with these areas.
EX PC 1394
LOCK
A
HJILM
K
N
EF
R
O
S
P
F
CDBG
Q
Right side
Rear side Bottom
(Example: USB port cover)
