Appendix
Specifications
This page provides the specifications for the basic model. The model number is different accord-
ing to the unit configuration.
l
To check the model number:
Check the bottom of the computer or the box the computer came in at the time of purchase.
l
To check memory size and the ash memory drive (SSD) size:
Run the Setup Utility (
è
Reference Manual “Setup Utility”) and select [Information] menu.
[Memory Size]: Memory size, [Hard Disk]: Hard disk drive size
Main Specifications
Model No. CF-AX3EDC series CF-AX3EDW series
CPU/Secondary cache memory
Intel
®
Core™ i5-4300U vPro™ Processor (3
MB
*1
cache, up to 2.90
GHz
)
with Intel
®
Turbo Boost Technology
Chipset Built-in CPU
Video controller Intel
®
HD Graphics 4400 (Built-in CPU)
Main Memory
*2
4
GB
*1
(Option: 8
GB
*1
), DDR3L SDRAM
Memory expansion is not possible.
Video Memory
*1*3
UMA 1792
MB
Max.
UMA <32-
bit
> 1553 MB Max. <64-
bit
> 1696 MB Max.
Flash Memory Drive (SSD)
*4
128
GB
(Option: 256
GB
)
Approx. <For localized OS model> 15
GB
/ <For MUI OS model> 15
GB
(SSD Recovery partition) and approx. 1
GB
(Recovery partition) are used
as recovery partitions. (Users cannot use these partitions.)
<Only for Windows 7 downgrade model>
Approx. <For localized OS model> 30
GB
/ <For MUI OS model> 50
GB
is used as a partition with HDD recovery tools. (Users cannot use this
partition.)
Approx. 300
MB
is used as a partition with system tools. (Users cannot
use this partition.)
Display Method 11.6 Full HD type (IPS) (1920 x 1080 dots)
Internal LCD 65,536/16,777,216 colors (1920 x 1080 dots)
*5
External Display
*6
65,536/16,777,216 colors (1024 × 768 dots/1280 × 768 dots/
1280 × 1024 dots/1360 × 768 dots/1366 × 768 dots/1400 × 1050 dots/
1600 × 900 dots/1600 × 1200 dots/1680 × 1050 dots/1920 × 1080 dots/
1920 × 1200 dots)
Simultaneous Display on LCD
+ External Display
*6
65,536/16,777,216 colors (1024 × 768 dots/1280 × 768 dots/
1360 × 768 dots/1366 x 768 dots/1400 x 1050 dots/1600 x 900 dots/
1680 x 1050 dots/1920 x 1080 dots)
Wireless LAN Intel
®
Dual Band Wireless-N 7260 (
è
page 48)
Bluetooth
*7
Bluetooth v4.0
Wireless WAN
*8
Equipped for some models (
è
page 49)
LAN IEEE 802.3 10Base-T / IEEE 802.3u 100BASE-TX / IEEE 802.3ab
1000BASE-T
Sound WAVE and MIDI playback, Intel
®
High Denition Audio subsystem support
Security Chip TPM (TCG V1.2 compliant)
CF-AX3mk2_EU_M.indb 46 2013/11/18 12:12:59
