Panasonic CQ-C8401W

13 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
;
mark have special characteristics important for safety.
When replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
•
• •
• Order intake period is basically six months after the first
shipment.
5. "A" or "B" marks in remarks column are indicated as
follows :
•
• •
• A : CQ-C8401W
•
• •
• B : CQ-C7401W
Ref. No. Part No. Part Name & Description Remarks
[E3042] Main/Connector Block
IC´s AND TRANSISTORs
IC201 C1BB00000796 IC
IC241 C1BB00000650 IC
IC251 C1BB00000649 IC
IC271 C1EA00000043 IC
IC401 C1BB00000644 IC
IC601 C2CBJG000589 IC
IC630 YEAMT7ST08UL IC
IC650 YEAMT7ST08UL IC
IC670 YEAMC14584BE IC
IC701 C0DAZHF00004 IC
IC702 AN8065SE1 IC
IC730 C0DAEKG00002 IC
IC752 C0CAABG00012 IC
IC755 C0DBZGD00040 IC
IC760 C0GBG0000032 IC
PA51 C5BA00000123 Electronic Tuner
Q55 B1GDGFEH0001 Transistor
Q56 B1AAEC000002 Transistor
Q220 B1GBCFNN0004 Transistor
Q262 B1GBHBEA0004 Transistor
Q266 B1GBHBEA0004 Transistor
Q320 B1GBCFNN0004 Transistor
Q346 B1GBHBEA0004 Transistor
Q362 B1GBHBEA0004 Transistor
Q366 B1GBHBEA0004 Transistor
Q372 YEANC114YKX Transistor
Q376 B1GBCFNN0004 Transistor
Q411 YEAN2SK536TB Transistor
Q630 B1GBCFNN0004 Transistor
Q633 B1GDCFJJ0002 Transistor
Q650 YEANC114YKX Transistor
Q651 B1GBCFNN0004 Transistor
Q652 B1GBCFNN0004 Transistor
Q667 B1GBCFNL0001 Transistor
Q680 B1GDGFEH0001 Transistor
Q681 B1GDCFJJ0002 Transistor
Q701 2SD2139TA Transistor
Ref. No. Part No. Part Name & Description Remarks
Q730 B1GBCFNN0004 Transistor
Q731 B1GBCFNN0004 Transistor
Q760 B1GBCFNN0004 Transistor
Q790 YEANHQ1F3PT1 Transistor
Q791 YEANHQ1F3PT1 Transistor
Q792 YEANC114YKX Transistor
Q793 YEANC114YKX Transistor
DIODEs
D201 B0JCME000012 Diode
D202 B0JCME000012 Diode
D203 B0JCME000012 Diode
D204 B0JCME000012 Diode
D301 B0JCME000012 Diode
D302 B0JCME000012 Diode
D303 B0JCME000012 Diode
D304 B0JCME000012 Diode
D346 B0JCMC000004 Diode
D601 B0JCMC000004 Diode
D630 B3AAB0000143 Diode
D631 B0BC5R600003 Diode
D635 B0BC5R600003 Diode
D636 B0BC5R600003 Diode
D637 B0BC5R600003 Diode
D638 B0BC5R600003 Diode
D639 B0BC5R600003 Diode
D670 B0JCMC000004 Diode
D671 MA3X152A0L Diode
D701 YEADDAM3MA47 Diode
D702 MA736TX Diode
D703 YEADRD56M3T1 Diode
D704 B0JCMC000004 Diode
D705 B0JCME000012 Diode
D706 B0JCME000012 Diode
D707 YEADRB051L40 Diode
D708 MA736TX Diode
D710 B0JCMC000004 Diode
D715 MA3X152A0L Diode
D716 MA721TX Diode
D760 YEADRD51M2T1 Diode
D761 YEADRD30M2T1 Diode
D770 B0JCMC000004 Diode
D771 B0JCMC000004 Diode
CAPACITORs
C52 YECUS1H470JC Ceramic, 47PF 50WV
C53 F1J1H103A513 Ceramic, 0.01µF 50WV
C54 F2A1A221A449 Electrolytic, 220µF 10WV
C55 F1J1H103A513 Ceramic, 0.01µF 50WV
C56 F3F1E105A001 Tantalum, 1µF 25WV
C57 F2A1A101A450 Electrolytic, 100µF 10WV
C61 YECUS1H183KX Ceramic, 0.018µF 50WV
C62 YECUS1H183KX Ceramic, 0.018µF 50WV
C65 F1J1H1020024 Ceramic, 1000PF 50WV
C206 F2A1C100A502 Electrolytic, 10µF 16WV
C213 F1J1A2250004 Ceramic, 2.2µF 10WV
C215 F1J1A2250004 Ceramic, 2.2µF 10WV
C217 YECUS1C334KX Ceramic, 0.33µF 16WV
C220 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C244 YECUV2A152KX Ceramic, 1500PF 100WV
C245 F2A1C1010089 Electrolytic, 100µF 16WV
C246 YECUS1C104KX Ceramic, 0.1µF 16WV
C247 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C248 F2A0J470A558 Electrolytic, 47µF 6.3WV
C249 YECUS1C104KX Ceramic, 0.1µF 16WV
C251 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C254 F1J1H152A675 Ceramic, 1500PF 50WV
C255 F2A1C1010089 Electrolytic, 100µF 16WV
C257 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C259 YECUS1C104KX Ceramic, 0.1µF 16WV
C261 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C263 ECQV1H474JL2 Plastic Film, 0.47µF 50WV
21
CQ-C8401W / CQ-C7401W
