15 CD PLAYER PARTS LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
·
Order intake period is basically six months after the first
shipment.
Ref. No. Part No. Part Name & Description Remarks
[3032-14-14] CD Servo Block
IC´s and TRANSISTORs
IC101 YESAM272 IC
IC201 YESAM279 IC
IC401 YESAM275 IC
IC402 YESAM280 IC
IC403 YESAM171 IC
IC404 YESAM178 IC
IC405 YESAM270 IC
Q101 YESAN086 Transistor
Q201 YESAN086 Transistor
CAPACITORs
C302 YESCC203 Ceramic, 220pF 50WV
C101 YESCC187 Ceramic, 0.1µF 25WV
C102 YESCC384 Ceramic, 0.033µF 50WV
C103 YESCC206 Ceramic, 0.047µF 25WV
C104 YESCC207 Ceramic, 0.001µF 50WV
C106 YESCC204 Ceramic, 330pF 50WV
C107 YESCC187 Ceramic, 0.1µF 25WV
C108 YESCC206 Ceramic, 0.047µF 25WV
C110 YESCC383 Ceramic, 0.33µF 10WV
C112 YESCC209 Ceramic, 0.0033µF 50WV
C113 YESCC187 Ceramic, 0.1µF 25WV
C114 YESCC298 Ceramic, 0.015µF 50WV
C115 YESCC187 Ceramic, 0.1µF 25WV
C116 YESCC382 Ceramic, 680pF 50WV
C117 YESCC207 Ceramic, 0.001µF 50WV
C118 YESCC187 Ceramic, 0.1µF 25WV
C119 YESCC187 Ceramic, 0.1µF 25WV
C120 YESCC187 Ceramic, 0.1µF 25WV
C121 YESCC187 Ceramic, 0.1µF 25WV
C122 F1H1H101A231 Ceramic, 100pF 50WV
C124 YESCC187 Ceramic, 0.1µF 25WV
C125 YESCC187 Ceramic, 0.1µF 25WV
C151 YESCC388 Electrolytic, 100µF 16WV
C154 YESCC390 Electrolytic, 220µF 10WV
C204 YESCC209 Ceramic, 0.0033µF 50WV
C205 YESCC184 Ceramic, 0.0047µF 50WV
C206 YESCC187 Ceramic, 0.1µF 25WV
C207 YESCC202 Ceramic, 22pF 50WV
C210 YESCC187 Ceramic, 0.1µF 25WV
C251 YESCC390 Electrolytic, 220µF 10WV
C252 YESCC390 Electrolytic, 220µF 10WV
C253 YESCC389 Electrolytic, 470µF 6.3WV
C301 YESCC203 Ceramic, 220pF 50WV
Ref. No. Part No. Part Name & Description Remarks
C303 YESCC185 Ceramic, 0.01µF 50WV
C304 YESCC185 Ceramic, 0.01µF 50WV
C305 YESCC382 Ceramic, 680pF 50WV
C306 YESCC382 Ceramic, 680pF 50WV
C307 YESCC187 Ceramic, 0.1µF 25WV
C351 YESCC381 Ceramic, 10µF 6.3WV
C352 YESCC381 Ceramic, 10µF 6.3WV
C353 YESCC391 Electrolytic, 100µF 16WV
C354 YESCC390 Electrolytic, 220µF 10WV
C401 YESCC187 Ceramic, 0.1µF 25WV
C402 YESCC187 Ceramic, 0.1µF 25WV
C403 YESCC187 Ceramic, 0.1µF 25WV
C404 YESCC187 Ceramic, 0.1µF 25WV
C405 YESCC187 Ceramic, 0.1µF 25WV
C406 YESCC187 Ceramic, 0.1µF 25WV
C407 YESCC187 Ceramic, 0.1µF 25WV
C408 YESCC210 Ceramic, 1µF 16WV
C409 YESCC187 Ceramic, 0.1µF 25WV
C410 YESCC210 Ceramic, 1µF 16WV
C411 YESCC187 Ceramic, 0.1µF 25WV
C412 YESCC187 Ceramic, 0.1µF 25WV
C413 YESCC187 Ceramic, 0.1µF 25WV
C414 YESCC187 Ceramic, 0.1µF 25WV
C415 YESCC187 Ceramic, 0.1µF 25WV
C416 YESCC210 Ceramic, 1µF 16WV
C417 YESCC187 Ceramic, 0.1µF 25WV
C418 YESCC210 Ceramic, 1µF 16WV
C419 YESCC187 Ceramic, 0.1µF 25WV
C421 YESCC210 Ceramic, 1µF 16WV
C422 YESCC187 Ceramic, 0.1µF 25WV
C451 YESCC389 Electrolytic, 470µF 6.3WV
C452 YESCC389 Electrolytic, 470µF 6.3WV
C454 YESCC388 Electrolytic, 100µF 16WV
RESISTORs
J101-105 ERJ8GX0R00V Chip, 0
Ω
1/4W
L102 YESRG241 Chip, 0
Ω
L201 YESRG241 Chip, 0
Ω
L304 YESRG241 Chip, 0
Ω
R101 YESRG234 Chip, 4.7
Ω
1/10W
R102 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R103 YESRG227 Chip, 2.2k
Ω
1/10W
R104 YESRG227 Chip, 2.2k
Ω
1/10W
R105 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R106 YESRG230 Chip, 3.3k
Ω
1/10W
R107 YESRG230 Chip, 3.3k
Ω
1/10W
R108 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R109 YESRG238 Chip, 56k
Ω
1/10W
R110 YESRG228 Chip, 22k
Ω
1/10W
R114 YESRG240 Chip, 82k
Ω
1/10W
R116 YESRG239 Chip, 820
Ω
1/10W
R117 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R118 YESRG223 Chip, 10k
Ω
1/10W
R119 YESRG233 Chip, 47k
Ω
1/10W
R120 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R121 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R122 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R123 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R124 YESRG224 Chip, 100k
Ω
1/10W
R125 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R126 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R127 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R128 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R201 YESRG243 Chip, 6.8k
Ω
1/10W
R202 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R204 YESRG222 Chip, 1k
Ω
1/10W
R205 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R206 YESRG242 Chip, 15k
Ω
1/10W
R207 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R208 YESRG228 Chip, 22k
Ω
1/10W
R209 ERJ3GEY0R00V Chip, 0
Ω
1/4W
R211 YESRG233 Chip, 47k
Ω
1/10W
R215 YESRG237 Chip, 5.6k
Ω
1/10W
28
CQ-C8401W / CQ-C7401W
