CS-A181KR / CU-A181KR
CS-A241KR / CU-A241KR
Block Diagram
POWER
SWITCH
INDOOR UNIT OUTDOOR UNIT
SINGLE PHASE AC 240-230V 50Hz
(113°C)
THERMAL FUSE
22 11
WIRELESS
REMOTE CONTROL TRANSMITTER
LH
C
ZNR
RY-PWR
RY-HOT
ELECTRONIC CONTROLLER
4 4
33
TRANSFORMER2
FUSE 3.15A
FUSE 3.15A
ZNR2
RY-HOT
ZNR1
COMP
F/M
RY-V
RY-OFF
RY-DEICE
2-WAY
TRANSFORMER1
RY-H/L
TRANS- FORMER
4-WAY VALVE
VALVE
CU-A241K ONLY
O.L.P.
P.C.B.
RECEIVER
SENSOR
6C
S/M
INDICATORS
5C
4C
SENSOR
4C
ZNR3 ZNR4
3C
F/M
ELECTRONIC CONTROLLER
THERMAL
FUSE (102°C)
Indicates the number of core wires. (Example: 6C=6 core wires)
"C"
Indicates the electronic control unit.
MAIN
PC1
ZNR2
STEPPING
MOTOR
FAN MOTOR
INDOOR
