Panasonic CS-A181KR

– 45 –
MAC9512086C2
CS-A181KR
Electronic Parts List
PART NO.
A52D011W216
A52C096
A52C050
A52MPA2003C
A52BR9020
A52MPC393C
A52BX8315
A52LP620-G4
A55C130
A55D2220QTA
A55DTC114EST
A55C1740STPQ
A55C1741ASTR
A55DTA143XST
A52C071
A52C070
A54D3SBA60F1
A54CS1VB20E
A54RB44-08V
A54C198
A541SS131T
A54RA15-01KB
A54MA165TA5
A54MA723TA
A54D8.2EL2TB
A54C353
A43101T
A43036
A49219
A49220
A401005(CS–A181K ONLY), A40287(CS–A241K ONLY)
A40263
A00161
A00106
A04042
A01059
XBA2C31TR0
A45ST8.0MTWT
A48039
A44EVMEASB52
A16C204
DESCRIPTION & NAME
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
PHOTO COUPLER
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
DIODE BRIDGE
DIODE BRIDGE
DIODE
DIODE
DIODE
DIODE
DIODE
DIODE
ZENER DIODE
ZNR
V - COIL
V - COIL
NOISE FILTER
NOISE FILTER
TRANSFORMER
TRANSFORMER
RELAY ELECTRO MAGNETIC
RELAY ELECTRO MAGNETIC
SLIDE SWITCH
PUSH SWITCH
FUSE
RESONATOR
BUZZER (SOUND GENERATOR)
VARIABLE RESISTOR
FUSE COMPLETE
SYMBOL
IC1
IC2
IC3
IC4
IC5
IC6
IC7
PC
Q1
Q2
Q3, Q5, Q7~Q9, Q13 ~ Q15
Q4
Q6
Q10 ~ Q12
Q16
Q17
DB1
DB2
D1
D2
D3
D6
D7 ~ D13, D16 ~ D23
D24
ZD1
ZNR1, ZNR2
L1
L2 ~ L6
LF1
LF2
T1
T2
RY - HOT
RY - PWR
SW1
SW2, SW3
FUSE
X1
BZ
VR1
FUSE
(Note) ● All parts are supplied from MACC, Malaysia (Vendor Code: 086).
Electronic Controller : CWA742082 (CS-A181K)
Electronic Controller : CWA742083 (CS-A241K)
