Panasonic CS-A181KR

– 46 –
MAC9512086C2
CS-A181KR
Electronic Parts List
Electronic Controller : CWA741314 (CU-A181K)
Electronic Controller : CWA741315 (CU-A241K)
PART NO.
A52C78414Y
A52C094
A52C040
A52MPA2003C
A55C1740STPQ
A55DTC113ZST
A54MA165TA5
A54CS1VB20E
A54D7.5EL1TB
A54C353
A40378
A59014
A59014 ( CU-A241K ONLY)
A00160
A00160
A00160
A00160
A00160 (CU-A241K ONLY)
XBA2C31TR0
A45ST4.0MGWT
SYMBOL
IC1
IC2
IC3
IC4
Q1
Q2
D1 ~ D6
DB1, DB2
ZD1
ZNR2 ~ ZNR4
T1, T2
CR1
CR2
RY-HOT
RY-DEICE
RY-OFF
RY-H/L
RY-V
FUSE
X1
DESCRIPTION & NAME
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
INTEGRATED CIRCUIT
TRANSISTOR
TRANSISTOR
DIODE
DIODE BRIDGE
ZENAR DIODE
ZNR
TRANSFORMER
SURGE ABSORBER
SURGE ABSORBER
RELAY
RELAY
RELAY
RELAY
RELAY
FUSE
RESONATOR
(Note) ● All parts are supplied from MACC, Malaysia (Vendor Code: 086).
