6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb)
and outdoor air temperature of 35C Dry Bulb (95F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry
Bulb (44.6°FDry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb)
3. Specifications are subjected to change without prior notice for further improvement.
Indoor Airflow
Lo
m
3
/min (ft
3
/m)
Cooling: 13.8 (486) - 13.8 (486)
Heating: 14.8 (523) - 14.8 (523)
Cooling: 15.4 (543) - 15.4 (543)
Heating: 16.6 (587) - 16.6 (587)
Me
m
3
/min (ft
3
/m)
Cooling: 15.1 (532) - 15.1 (532)
Heating: 15.3 (542) - 15.3 (542)
Cooling: 17.0 (600) - 17.0 (600)
Heating: 17.2 (606) - 17.2 (606)
Hi
m
3
/min (ft
3
/m)
Cooling: 16.4 (579) - 16.4 (579)
Heating: 17.1 (604) - 17.1 (604)
Cooling: 18.6 (657) - 18.6 (657)
Heating: 20.0 (706) - 20.0 (706)
SHi
m
3
/min (ft
3
/m)
16.8 (593) - 16.8 (593) 19.8 (699) - 19.8 (699)
Outdoor Airflow
Lo
m
3
/min (ft
3
/m)
28.6 (1010) - 30.5 (1080) 28.1 (990) - 29.9 (1060)
Hi
m
3
/min (ft
3
/m)
50.7 (1790) - 51.7 (1830) 49.7 (1750) - 50.7 (179)
Refrigeration Cycle
Control Device Capillary Tube Capillary Tube
Refrigerant Oil
cm
3
SUNISO 4GDID or ATMOS
NM56M (700)
SUNISO 4GDID or ATMOS
NM56M (1130)
Refrigerant Type g (oz) R22, 1710 (60.4) R22, 2050 (72.4)
Dimension
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 750 (29-17/32) 290 (11-7/16) / 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32) 1070 (42-5/32) / 875 (34-15/32)
Depth (I/D / O/D) mm (inch) 235 (9-9/32) / 345 (13-19/32) 235 (9-9/32) / 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 60 (132) 12 (26) / 60 (132)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4”) / 12.7 (1/2”) 6.35 (1/4”) / 15.8 (5/8”)
Standard length m (ft) 5 (16.4) 7.5 (24.6)
Length range (min~max) m (ft) 3~25 (9.8~82.0) 3~25 (9.8~82.0)
I/D & O/D Height different m (ft) 20.0 (65.6) 20.0 (65.6)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 30 (0.3)
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Drain Hose
Inner Diameter mm 12 12
Length mm 560 560
Indoor Heat Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row  Stage  FPI 2  15  21 2  15  21
Size (W  H  L) mm 810  315  25.4 810  315  25.4
Outdoor Heat Exchanger
Fin Material Aluminium (Blue Coat) Aluminium (Blue Coat)
Fin Type Corrugated Fin Corrugated Fin
Row  Stage  FPI 2  28  17 2  23  17
Size (W  H  L) mm 44  711.2  782.4
816.9
44  711.2  782.4
816.9
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Indoor Power Supply Indoor Power Supply
Power Supply Cord A 16 20
Thermostat ——
Protection Device Inner Protector —
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Indoor Operation Range
Cooling
Maximum 32 23 32 23
Minimum 16 11 16 11
Heating
Maximum 30 — 30 —
Minimum 16 — 16 —
Outdoor Operation Range
Cooling
Maximum 43 26 43 26
Minimum 16 11 16 11
Heating
Maximum 24 18 24 18
Minimum -5 -6 -5 -6
