66
(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CS-A18JKD CS-A24JKD REMARKS
1 CHASSY COMPLETE 1 CWD50C1623 
2 FAN MOTOR 1 L6CBYYYL0037 ARW7614AC O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1077 
4 BEARING ASS’Y 1 CWH64K007 
5 SCREW - CROSS FLOW FAN 1 CWH551146 
6 ION GENERATOR 1 CWH94C0028 
7 EVAPORATOR CO. 1 CWB30C2730 CWB30C2779
8 FLARE NUT (LIQUID) 1 CWT251026 
9 FLARE NUT(GAS) 1 CWT251035 CWT251036
10 E-ION AIR PURIFYING SYSTEM 1 CWD93C1090 
11 E-ION AIR PURIFYING SYSTEM 1 ––
12 CLIP FOR SENSOR 1 CWH32143 
13 CONTROL BOARD CASING 1 CWH102370 
14 TERMINAL BOARD COMPLETE 1 CWA28C2359 CWA28C2360 O
15 P.S.CORD 1 CWA20C2829 CWA20C2836
16 ELECTRONIC CONTROLLER - MAIN 1 CWA73C3751 CWA73C3740 O
17 ELECTRONIC CONTROLLER - POWER 1 CWA745304  O
18 ELECTRONIC CONTROLLER-HVU 1 CWA745348 
19 ELECTRONIC CONTROLLER-INDICATOR 1 CWA745299 
20 ELECTRONIC CONTROLLER-RECEIVER 1 CWA745288 
21 SENSOR COMPLETE 1 CWA50C2401  O
22 CONTROL BOARD TOP COVER 1 CWH131350 
23 INDICATOR COMPLETE 1 ––O
24 INDICATOR HOLDER 1 CWD933021 
25 INDICATOR HOLDER 1 ––
26 CONTROL BOARD FRONT COVER 1 CWH13C1183 
27 DISCHARGE GRILLE COMPLETE 1 CWE20C3007 
28 FULCRUM 2 CWH621103 
29 VERTICAL VANE 15 CWE241289 
30 CONNECTING BAR 1 CWE261156 
31 CONNECTING BAR 1 CWE261158 
32 CONNECTING BAR 1 CWE261157 
33 CONNECTING BAR 1 CWE261159 
34 CONNECTING BAR 1 CWE261160 
35 A.S.MOTOR DC SINGLE 12V300 OHM 1 CWA98K1014  O
36 LEAD WIRE-COMPLETE (AIR SWING MOTOR) 1 ––
37 A.S.MOTOR DC SINGLE 12V300 OHM 1 CWA981154J  O
38 LEAD WIRE-COMPLETE (AIR SWING MOTOR) 1 CWA67C8221 
39 CAP - DRAIN TRAY 1 CWH521096 
40 HORIZONTAL VANE COMPLETE 1 CWE24C1295 
41 BACK COVER CHASSIS 1 CWD933031 
42 REMOTE CONTROL COMPLETE 1 CWA75C3165  O
43 FRONT GRILLE COMPLETE 1 CWE11C4256 CWE11C4082 O
44 INTAKE GRILLE COMPLETE 1 CWE22C1483 
45 GRILLE DOOR COMPLETE 1 CWE14C1029 
46 E-ION FILTER 2 CWD00K1015 
47 SCREW - FRONT GRILLE 4 XTT4+16CFJ 
48 CAP - FRONT GRILLE 3 CWH521194 
49 DRAIN HOSE 1 CWH851063 
50 INSTALLATION PLATE 1 CWH361098 
51 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067

52
OPERATING INSTRUCTION 1 CWF566338 
53 INSTALLATION INSTRUCTION 1 CWF613671 
54 INSTALLATION INSTRUCTION 1 CWF613672 
55 INSTALLATION INSTRUCTION 1 CWF613673 
56 INSTALLATION INSTRUCTION 1 CWF613674 
57 INSTALLATION INSTRUCTION 1 CWF613675 
58 INSTALLATION INSTRUCTION 1 CWF613676 
