Panasonic CS-A9KKD - Page 6

6
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6 poles) Induction (6 poles)
Input Power W 55.6 - 63.1 65 - 73
Output Power W 30 30
Outdoor Fan
Speed Hi rpm 800 - 830 835 - 845
Moisture Removal L/h (Pt/h) 1.6 (3.4) 2.0 (4.2)
Lo m
3
/min (ft
3
/min)
Cooling: 7.4 (263) - 7.4 (263)
Heating: 8.3 (292) - 8.3 (292)
Cooling: 7.9 (277) - 7.9 (277)
Heating: 8.4 (297) - 8.4 (297)
Me m
3
/min (ft
3
/min)
Cooling: 8.9 (313) - 8.9 (313)
Heating: 9.2 (326) - 9.2 (326)
Cooling: 9.3 (329) - 9.3 (329)
Heating: 9.5 (335) - 9.5 (335)
Hi m
3
/min (ft
3
/min)
Cooling: 10.2 (360) - 10.2 (360)
Heating: 10.6 (374) - 10.6 (374)
Cooling: 10.8 (381) - 10.8 (381)
Heating: 11.0 (388) - 11.0 (388)
Indoor Airflow
SHi m
3
/min (ft
3
/min)
Cooling: 10.6 (374) - 10.6 (374)
Heating: 11.0 (389) - 11.0 (389)
Cooling: 11.0 (388) - 11.0 (388)
Heating: 11.2 (396) - 11.2 (396)
Outdoor
Airflow
Hi m
3
/min (ft
3
/min) 29.5 (1040) - 30.0 (1060) 32.5 (1150) - 33.0 (1160)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
Suniso 4GDID or ATMOS NM56M (350) Suniso 4GDID or ATMOS NM56M (350)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 670 (23.7) R22, 1010 (35.7)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 510 (20-3/32) 290 (11-7/16) / 540 (21-9/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 650 (25-19/32) 870 (34-9/32) / 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 204 (8-1/16) / 230 (9-1/16) 204 (8-1/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 27 (60) 9 (20) / 33 (73)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.7 (1/2)
Standard length m (ft) 7.5 (24.6) 7.5 (24.6)
Length range (min – max) m (ft) 3 ~ 10 (9.8 ~ 32.8) 3 ~ 15 (9.8 ~ 49.2)
I/D & O/D Height different m (ft) 5 (16.4) 5 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 16 16
Drain Hose
Length mm 650 650
Fin Material Aluminium (Pre coated) Aluminium (Pre coated)
Fin Type Slit Fin Slit Fin
Row x Stage x
FPI
2 x 10 x 19 2 x 15 x 21
Indoor Heat
Exchanger
Size (W x H x L) mm 610 x 315 x 25.4 610 x 315 x 25.4
Fin Material Aluminium (Blue coated) Aluminium (Blue coated)
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x
FPI
1 x 19 x 17 2 x 24 x 17
Outdoor Heat
Exchanger
Size (W x H x L) mm 22.0 x 482.6 x 567.4 36.38 x 504 x 675.4:704.4
Material Polypropelene Polypropelene
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 10 10
Thermostat - -
Protection Device 2 stage Overload Protector Overload Protector
DRY BULB WET BULB DRY BULB WET BULB
Maximum 32 23 32 23
Cooling
Minimum 16 11 16 11
Maximum 30 - 30 -
Indoor
Operation
Range
Heating
Minimum 16 - 16 -
