Indoor CS-A9PKD CS-A12PKD
Model
Outdoor CU-A9PKD CU-A12PKD
QLo m
3
/min (ft
3
/min)
Cooling: 6.4 (226) - 6.4 (226)
Heating: 6.8 (240) - 6.8 (240)
Cooling: 7.1 (251) - 7.1 (251)
Heating: 7.5 (265) - 7.5 (265)
Lo m
3
/min (ft
3
/min)
Cooling: 7.1 (251) - 7.1 (251)
Heating: 7.5 (265) - 7.5 (265)
Cooling: 7.8 (275) - 7.8 (275)
Heating: 8.2 (290) - 8.2 (290)
Me m
3
/min (ft
3
/min)
Cooling: 8.5 (300) - 8.5 (300)
Heating: 8.5 (300) - 8.5 (300)
Cooling: 9.3 (328) - 9.3 (328)
Heating: 9.3 (328) - 9.3 (328)
Hi m
3
/min (ft
3
/min)
Cooling: 10.2 (360) - 10.2 (360)
Heating: 10.6 (374) - 10.6 (374)
Cooling: 10.8 (381) - 10.8 (381)
Heating: 11.0 (388) - 11.0 (388)
Indoor Airflow
SHi m
3
/min (ft
3
/min) Cooling: 10.6 (374) - 10.6 (374) Cooling: 11.0 (388) - 11.0 (388)
Outdoor
Airflow
Hi m
3
/min (ft
3
/min) 29.5 (1040) - 30.0 (1060) 32.5 (1150) - 33.0 (1160)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
ATMOS NM56M or SUNISO 4GDID (350) ATMOS NM56M or SUNISO 4GDID (350)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 670 (23.7) R22, 960 (33.9)
Height (I/D / O/D) mm (inch) 290 (11-7/16) 511 (20-1/8) 290 (11-7/16) 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) 650 (25-19/32) 870 (34-9/32) 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) 230 (9-1/16) 214 (8-7/16) 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) 26 (57) 9 (20) 29 (64)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 7.5 (24.6) 7.5 (24.6)
Length range (min – max) m (ft) 3 (9.8) ~ 10 (32.8) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 5 (16.4) 5 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 16.7 16.7
Drain Hose
Length mm 650 650
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 15 × 21 2 × 15 × 21
Indoor Heat
Exchanger
Size (W × H × L) mm 610 × 315 × 25.4 610 × 315 × 25.4
Fin Material Aluminium (Blue Coat) Aluminium (Blue Coat)
Fin Type Corrugate Fin Corrugate Fin
Row × Stage × FPI 1 × 19 × 19 2 × 24 × 17
Outdoor Heat
Exchanger
Size (W × H × L) mm 22 × 483 × 567 36.38 × 504 × 684.0:715.0
Material Polypropelene Polypropelene
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 10 10
Thermostat – –
Protection Device 2-Stage Overload Protector 2-Stage Overload Protector
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Maximum °C 32 23 32 23
Cooling
Minimum °C 16 11 16 11
Maximum °C 30 – 30 –
Indoor
Operation
Range
Heating
Minimum °C 16 – 16 –
Maximum °C 43 26 43 26
Cooling
Minimum °C 16 11 16 11
Maximum °C 24 18 24 18
Outdoor
Operation
Range
Heating
Minimum °C -5 -6 -5 -6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb)
3. Specifications are subjected to change without prior notice for further improvement.
