2 Specifications
2.1. CS-C12HKF CU-C12HKF
1. Cooling capacities are based on indoor temperature of 27qC D.B. (80.6qF D.B.), 19.0qC W.B. (66.2qF W.B.) and outdoor air
temperature of 35qC D.B. (95qF D.B.), 24qC W.B. (75.2qF W.B.)
2. Heating capacities are based on indoor temperature of 20qC D.B. (80.6qF D.B.) and outdoor air temperature of 7qC D.B.
(44.6qF D.B.), 6qC W.B. (42.8qF W.B.)
Item Unit Indoor unit Outdoor unit
Performance Test Condition JIS
Capacity kW 3.58 - 3.60
BTU/h 12200 - 12300
*kJ/h 12890 - 12960
EER W/W 3.17 - 3.10
BTU/hW 10.8 - 10.6
Noise Level dB (A) High: 39 Low: 29 High: 48 / 49
Power level dB High: 97 —
Moisture Removal l/h 2.1
(pt/h) 4.4
Air Volume Lo
m
3
/m (ft
3
/m)
6.9 (243) - 6.9 (243) —
Me
m
3
/m (ft
3
/m)
8.1 (286) - 8.1 (286) —
Hi
m
3
/m (ft
3
/m)
9.7 (343) - 9.7 (343) 30.3 (1070) - 31.3 (1100)
SHi
m
3
/m (ft
3
/m)
10.1 (356) - 10.1 (356) —
Refrigerant Control Device — Capillary Tube
Refrigerant Oil (Charged)
cm
3
— ATMOS M60 or
SUNISO 4GDID (350cm
3
)
Refrigerant (Charged) R22 kg (oz) — 0.87 (30.7)
Dimension Height mm (inch) 280 (11 - 1/32) 540 (21 - 1/4)
Width mm (inch) 799 (31 - 15/32) 780 (30 - 23/32)
Depth mm (inch) 183 (7 - 7/32) 289 (11 - 3/8)
Net Weight kg (lbs) 9 (20) 37 (82)
Pipe Diameter Gas mm (inch) 12.70 (1/2”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) - 15 (49.2)
Additional Gas Amount g/m (oz/ft) 10 (0.1)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner diameter mm 16 —
Length mm 650 —
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 1.0k
Fan Type Cross-flow Fan Propeller Fan
Material ASG20K1 PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input power W 44.9 - 47.1 67.0 - 75.0
Output power W 15 31.1 - 35.6
Fan Speed Lo (Cool) rpm 900 - 900 —
Me (Cool) rpm 1060 - 1060 —
Hi (Cool) rpm 1270 - 1270 830 - 855
SHi (Cool) rpm 1320 - 1320 —
Heat Exchanger Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row u Stage u FPI 2 u 15 u 21 1 u 20 u 17
Size (W u H u L) mm (inch) 610 u 315 u 25.4 22 u 508 u 717
Air Filter Type Material Polypropelene —
Style One-touch —
