56
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
REF. NO. PART NAME & DESCRIPTION QTY. CS-C12HKF
1 CHASSY COMPLETE 1 CWD50C1572
2 FAN MOTOR, AC 15W SINGLE 1 CWA921181J
3 CROSS FLOW FAN COMPLETE 1 CWH02C1045
4 BEARING ASS’Y 1 CWH64K007
5 SCREW - CROSS FLOW FAN 1 CWH551146
6 ION GENERATOR 1 CWH94C0014
7 EVAPORATOR CO. 1 CWB30C2370
8 FLARE NUT (1/4”) 1 CWT251026
9 FLARE NUT (3/8”) (1/2”) 1 CWT25007
10 E-ION AIR PURIFYING SYSTEM 1 CWH14C5332
11 CLIP FOR SENSOR 1 CWH32143
12 DISCHARGE GRILLE COMPLETE 1 CWE20C2627
13 VERTICAL VANE 12 CWE241157
14 CONNECTING BAR 1 CWE261092
15 CONNECTING BAR 2 CWE261071
16 CONNECTING BAR 1 CWE261091
17 A.S.MOTOR, DC SINGLE 12V300 OHM 1 CWA981091
18 CAP - DRAIN TRAY 1 CWH521096
19 HORIZONTAL VANE COMPLETE 1 CWE24C1183
20 BACK COVER CHASSIS 1 CWD932454
21 CONTROL BOARD CASING 1 CWH102321
22 TERMINAL BOARD COMPLETE 1 CWA28C2311
23 P.S.CORD W/OUT PLUG 1 CWA20C2552
24 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2975
25 ELECTRONIC CONTROLLER - POWER 1 CWA744978W
26 SENSOR COMPLETE 1 CWA50C2122
27 CONTROL BOARD TOP COVER 1 CWH131207
28 INDICATOR COMPLETE 1 CWE39C1183
29 INDICATOR HOLDER 1 CWD932744
30 INDICATOR HOLDER 1 CWD932745
31 CONTROL BOARD FRONT COVER 1 CWH13C1171
32 REMOTE CONTROL COMPLETE 1 CWA75C3169
33 FRONT GRILLE COMPLETE 1 CWE11C3911
34 INTAKE GRILLE COMPLETE 1 CWE22C1409
35 GRILLE DOOR COMPLETE 1 CWE14C1010
36 E-ION FILTER 2 CWD00K1004
37 SCREW - FRONT GRILLE 2 XTT4+16CFJ
38 CAP - FRONT GRILLE 2 CWH521109
39 DRAIN HOSE 1 CWH851063
40 INSTALLATION PLATE 1 CWH361067
41 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
42 FULCRUM 1 CWH621049
