(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
[PHAAM] Printed in Malaysia
SSTH0711-00
REF. NO. PART NAME & DESCRIPTION QTY. CU-C18HKQ CU-C24HKQ
1 CHASSY ASS’Y 1 CWD50K2115 CWD50K2100
2 COMPRESSOR 1 2K25S236F6A 2J39S236A1A
3 ANTI - VIBRATION BUSHING 3 CWH50055 m
4 NUT - COMPRESSOR MOUNT 3 CWH561049 m
5 PACKING - COM.MOUNT 3 CWB81043 m
6 CONDENSER 1 CWB32C2228 CWB32C2229
7 SOUND PROOF BOARD 1 CWH151051 m
8 FAN MOTOR BRACKET 1 CWD541065 m
9 SCREW - FAN MOTOR BRACKET 2 CWH551217 m
10 FAN MOTOR 1 CWA951401J CWA951399J
11 SCREW - FAN MOTOR MOUNT 3 CWH55252J m
12 PROPELLER FAN ASS’Y 1 CWH03K1017 m
13 NUT - PROPELLER FAN 1 CWH561038J m
14 HOLDER COUPLING 1 CWH351036 m
15 3-WAY VALVE (LIQUID) 1 CWB011161 m
16 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT023522 CWT023554
17 3-WAY VALVE (GAS) 1 CWB011483 CWB011484
18 OVERLOAD PROTECTOR CO. 1 CWA121264 —
19 TERMINAL COVER 1 CWH171011 CWH171012
20 NUT - TERMINAL COVER 1 CWH7080300J m
21 CAPACITOR - F.M (3.5PF, 440V) 1 DS441355NPQA m
22 CAPACITOR - COMPRESSOR (40PF, 400V)(60PF, 440V) 1 CWA312078 DS441606CPNA
23 HOLDER CAPACITOR 1 CWH30060 CWH30071
24 TERMINAL BOARD ASS’Y 1 CWA28K1064J m
25 CABINET SIDE PLATE (L) 1 CWE041254A m
26 HANDLE 1 CWE161010 m
27 CABINET SIDE PLATE COMPLETE 1 CWE04C1101 m
28 HANDLE 2 CWE16000E m
29 CABINET FRONT PLATE ASS’Y 1 CWE06K1043 m
30 CABINET TOP PLATE ASS’Y 1 CWE031009A m
31 CONTROL BOARD COVER (BOTTOM) 1 CWH131168 m
32 CONTROL BOARD COVER (TOP) 1 CWH131169A m
33 OPERATION INSTRUCTIONS 1 CWF565778 m
34 INSTALLATION INSTRUCTIONS 1 CWF613347 m
35 THERMOSTAT 1 — CWA151040
36 STRAINER 1 CWB11025 m
37 SOUND PROOF MATERIAL 1 CWG302407 m
