2.2. CS-C24HKQ CU-C24HKQ
1. Cooling capacities are based on indoor temperature of 27qC D.B. (80.6qF D.B.), 19.0qC W.B. (66.2qF W.B.) and outdoor air
temperature of 35qC D.B. (95qF D.B.), 24qC W.B. (75.2qF W.B.)
Item Unit Indoor unit Outdoor unit
Performance Test Condition NEW JIS
Capacity kW 7.03
BTU/h 24000
*kJ/h 25310
EER W/W 2.72
kJ/hW 9.81
Noise Level dB (A) High: 46 Low: 40 High: 56 / -
Power level dB — —
Moisture Removal l/h 4.0
(pt/h) 8.5
Air Volume Lo
m
3
/m (ft
3
/m)
13.9 (493) —
Me
m
3
/m (ft
3
/m)
15.7 (553) —
Hi
m
3
/m (ft
3
/m)
16.9 (600) 52.5 (1850)
SHi
m
3
/m (ft
3
/m)
17.9 (632) —
Refrigerant Control Device — Capillary Tube
Refrigerant Oil (Charged)
cm
3
— ATMOS M60 or
SUNISO 4GDID (1130cm
3
)
Refrigerant (Charged) R22 kg (oz) — 1.41 (49.8)
Dimension Height mm (inch) 275 (10 - 27/32) 750 (29 - 17/32)
Width mm (inch) 998 (39 - 5/16) 875 (34 - 15/32)
Depth mm (inch) 230 (9 - 1/16) 345 (13 - 19/32)
Net Weight kg (lbs) 11 (24) 60 (132)
Pipe Diameter Gas mm (inch) 15.88 (5/8”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 20 (65.6)
Pipe Length Range m (ft) 3 (9.8) - 25 (82.0)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner diameter mm 16 —
Length mm 650 —
Compressor Type — Hermetic motor
Motor Type — Induction (2-poles)
Rated Output W — 1.8k
Fan Type Cross-flow Fan Propeller Fan
Material ASHT-18 PP Resin
Motor Type Transistor (8-poles) Induction (6-poles)
Input power W 60 158.6
Output power W 30 72
Fan Speed Lo (Cool) rpm 1240 —
Me (Cool) rpm 1390 —
Hi (Cool) rpm 1500 870
SHi (Cool) rpm 1590 —
Heat Exchanger Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Slit Fin
Row u Stage u FPI 2 u 15 u 21 2 u 34 u 17
Size (W u H u L) mm 810 u 315 u 25.4 25.4 u 714 u 814.8:834.8
Air Filter Type Material Polypropelene —
Style One-touch —
