Panasonic CS-C18PKF - Page 6

6
Control Device Capillary tube Capillary tube
Refrigerant Oil cm
3
ATMOS NM56M or SUNISO 4GDID (430) ATMOS NM56M or SUNISO 4GDID (450)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 870 (30.7) R22, 1.01k (35.7)
Height(I/D / O/D) mm (inch) 290 (11-7/16) 542 (21-11/32) 290 (11-7/16) 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) 780 (30-23/32) 1070 (42-5/32) 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) 289 (11-13/32) 240 (9-15/32) 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) 34 (75) 12 (26) 37 (82)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 7.5 (24.6) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 25 (82.0)
I/D & O/D Height different m (ft) 5 (16.4) 20 (65.6)
Additional Gas Amount g/m (oz/ft) 10 (0.1) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 16.7 16.7
Drain Hose
Length mm 650 650
Fin Material Pre Coat Pre Coat
Fin Type Slit Fin Slit Fin
Row x Stage x
FPI
2 X 15 X 21 2 x 15 x 17
Indoor Heat
Exchanger
Size (W x H x L) mm 610 x 315 x 25.4 810 x 315 x 25.4
Fin Material Blue Coated Blue Coated
Fin Type Corrugate Fin Slit Fin
Row x Stage x
FPI
1 X 20 X 17 2 x 24 x 17
Outdoor Heat
Exchanger
Size (W x H x L) mm 22 X 508 X 708.4:720.4 25.4 x 504 x 693.4:713.4
Material Polypropelene Polypropelene
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 15 16
Thermostat - -
Protection Device - -
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Maximum 32 23 32 23
Indoor Operation Range
Minimum 16 11 16 11
Maximum 55 31 55 31
Outdoor Operation Range
Minimum 16 11 16 11
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2.
Specifications are subjected to change without prior notice for further improvement.
