Panasonic CS-C7HKD Service Manual

5
2 Specifications
2.1. CS-C7HKD CU-C7HKD
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
Item Unit Indoor unit Outdoor unit
Performance Test Condition JIS
Capacity kW 2.00 - 2.02
BTU/h 6820 - 6890
kcal/h 1720 - 1740
EER W/W 3.39 - 3.15
BTU/hW 11.6 - 10.8
Noise Level dB (A) High: 33 Low: 26 High: 46 - 47
Power level dB High: 46 High: 61 - 62
Moisture Removal l/h 1.3
(pt/h) 2.7
Air Volume Lo
m
3
/m (ft
3
/m)
5.0 (175) - 5.0 (175) —
Me
m
3
/m (ft
3
/m)
5.8 (206) - 5.8 (206) —
Hi
m
3
/m (ft
3
/m)
6.7 (240) - 6.7 (240) 28.8 (1020) - 29.2 (1030)
SHi
m
3
/m (ft
3
/m)
7.7 (275) - 7.7 (275) —
Refrigerant Control Device — Capillary Tube
Refrigerant Oil (Charged)
cm
3
— ATMOS M60 or
SUNISO 4GDID (290cm
3
)
Refrigerant (Charged) R22 kg (oz) — 0.45 (15.9)
Dimension Height mm (inch) 280 (11 - 1/32) 510 (20 - 3/32)
Width mm (inch) 799 (31 - 15/32) 650 (25 - 19/32)
Depth mm (inch) 183 (7 - 7/32) 230 (9 - 1/16)
Net Weight kg (lbs) 9 (20) 22 (49)
Pipe Diameter Gas mm (inch) 9.52 (3/8”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) ~ 10 (32.8)
Additional Gas Amount g/m (oz/ft) 10 (0.1)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner diameter mm 16 —
Length mm 650 —
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 550
Fan Type Cross-flow Fan Propeller Fan
Material ASG20K1 PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input power W 55.0 - 66.0 66.0 - 75.0
Output power W 15 30
Fan Speed Lo (Cool) rpm 850 - 850 —
Me (Cool) rpm 1000 - 1000 —
Hi (Cool) rpm 1150 - 1150 800 - 830
SHi (Cool) rpm 1240 - 1240 —
Heat Exchanger Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 10 × 18 1 × 22 × 17
Size (W × H × L) mm (inch) 610 × 210 × 25.4 12.7 × 483 × 587
Air Filter Type Material Polypropelene —
Style One-touch —
