Panasonic CS-C7HKD Service Manual

9
2.3. CS-C12HKD CU-C12HKD
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
Item Unit Indoor unit Outdoor unit
Performance Test Condition JIS
Capacity kW 3.52 - 3.54
BTU/h 12000 - 12100
kcal/h 3030 - 3050
EER W/W 3.17 - 3.08
BTU/hW 10.8 - 10.5
Noise Level dB (A) High: 39 Low: 29 High: 48 - 49
Power level dB High: 52 High: 63 - 64
Moisture Removal l/h 2.1
(pt/h) 4.4
Air Volume Lo
m
3
/m (ft
3
/m)
6.9 (243) - 6.9 (243) —
Me
m
3
/m (ft
3
/m)
8.1 (286) - 8.1 (286) —
Hi
m
3
/m (ft
3
/m)
9.7 (343) - 9.7 (343) 30.9 (1090) - 32.3 (1140)
SHi
m
3
/m (ft
3
/m)
10.1 (356) - 10.1 (356) —
Refrigerant Control Device — Capillary Tube
Refrigerant Oil (Charged)
cm
3
— ATMOS M60 or
SUNISO 4GDID (410cm
3
)
Refrigerant (Charged) R22 kg (oz) — 0.49 (17.3)
Dimension Height mm (inch) 280 (11 - 1/32) 510 (20 - 3/32)
Width mm (inch) 799 (31 - 15/32) 650 (25 - 19/32)
Depth mm (inch) 183 (7 - 7/32) 230 (9 - 1/16)
Net Weight kg (lbs) 9 (20) 27 (60)
Pipe Diameter Gas mm (inch) 12.70 (1/2”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Additional Gas Amount g/m (oz/ft) 10 (0.1)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner diameter mm 16 —
Length mm 650 —
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 950
Fan Type Cross-flow Fan Propeller Fan
Material ASG20K1 PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input power W 55.0 - 66.0 59.4 - 67.3
Output power W 15 31
Fan Speed Lo (Cool) rpm 900 - 900 —
Me (Cool) rpm 1060 - 1060 —
Hi (Cool) rpm 1270 - 1270 815 - 850
SHi (Cool) rpm 1320 - 1320 —
Heat Exchanger Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 15 × 19 2 × 22 × 17
Size (W × H × L) mm (inch) 610 × 315 × 25.4 25.4 × 483 × 582
562
Air Filter Type Material Polypropelene —
Style One-touch —
