Panasonic CS-C7HKD Service Manual

7
2.2. CS-C9HKD CU-C9HKD
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
Item Unit Indoor unit Outdoor unit
Performance Test Condition JIS
Capacity kW 2.60 - 2.65
BTU/h 8870 - 9040
kcal/h 2240 - 2280
EER W/W 3.25 - 3.17
BTU/hW 11.1 - 10.8
Noise Level dB (A) High: 36 Low: 26 High: 46 - 47
Power level dB High: 49 High: 61 - 62
Moisture Removal l/h 1.6
(pt/h) 3.4
Air Volume Lo
m
3
/m (ft
3
/m)
4.6 (163) - 4.5 (160) —
Me
m
3
/m (ft
3
/m)
6.0 (212) - 5.9 (209) —
Hi
m
3
/m (ft
3
/m)
7.2 (250) - 7.1 (251) 28.8 (1020) - 29.2 (1030)
SHi
m
3
/m (ft
3
/m)
7.6 (269) - 7.5 (265) —
Refrigerant Control Device — Capillary Tube
Refrigerant Oil (Charged)
cm
3
— ATMOS M60 or
SUNISO 4GDID (350cm
3
)
Refrigerant (Charged) R22 kg (oz) — 0.49 (17.3)
Dimension Height mm (inch) 280 (11 - 1/32) 510 (20 - 3/32)
Width mm (inch) 799 (31 - 15/32) 650 (25 - 19/32)
Depth mm (inch) 183 (7 - 7/32) 230 (9 - 1/16)
Net Weight kg (lbs) 9 (20) 25 (55)
Pipe Diameter Gas mm (inch) 9.52 (3/8”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) ~ 10 (32.8)
Additional Gas Amount g/m (oz/ft) 10 (0.1)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner diameter mm 16 —
Length mm 650 —
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 750
Fan Type Cross-flow Fan Propeller Fan
Material ASG20K1 PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input power W 55.0 - 66.0 66.0 - 75.0
Output power W 15 30
Fan Speed Lo (Cool) rpm 800 - 800 —
Me (Cool) rpm 1040 - 1040 —
Hi (Cool) rpm 1250 - 1250 780 - 830
SHi (Cool) rpm 1320 - 1320 —
Heat Exchanger Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 10 × 18 1 × 22 × 17
Size (W × H × L) mm (inch) 610 × 210 × 25.4 12.7 × 483 × 600
Air Filter Type Material Polypropelene —
Style One-touch —
