(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
REF. NO. PART NAME & DESCRIPTION QTY. CS-C7HKD CS-C9HKD CS-C12HKD
1 CHASSY COMPLETE 1 CWD50C1572 ←←
2 FAN MOTOR, AC 15W SINGLE 1 CWA921324 ←←
3 CROSS FLOW FAN COMPLETE 1 CWH02C1045 ←←
4 BEARING ASS’Y 1 CWH64K007 ←←
5 SCREW - CROSS FLOW FAN 1 CWH551146 ←←
6 ION GENERATOR 1 CWH94C0014 ←←
7 EVAPORATOR CO. 1 CWB30C2326 ← CWB30C2408
8 FLARE NUT (1/4”) 1 CWT251026 ←←
9 FLARE NUT (3/8”) (1/2”) 1 CWT25005 ← CWT25007
10 E-ION AIR PURIFYING SYSTEM 1 CWH14C5332 ←←
11 CLIP FOR SENSOR 1 CWH32143 ←←
12 DISCHARGE GRILLE COMPLETE 1 CWE20C2627 ←←
13 VERTICAL VANE 12 CWE241157 ←←
14 CONNECTING BAR 1 CWE261092 ←←
15 CONNECTING BAR 2 CWE261071 ←←
16 CONNECTING BAR 1 CWE261091 ←←
17 A.S.MOTOR, DC SINGLE 12V300 OHM 1 CWA981091 ←←
18 CAP - DRAIN TRAY 1 CWH521096 ←←
19 HORIZONTAL VANE COMPLETE 1 CWE24C1183 ←←
20 BACK COVER CHASSIS 1 CWD932454 ←←
21 CONTROL BOARD CASING 1 CWH102321 ←←
22 TERMINAL BOARD COMPLETE 1 CWA28C2314 ← CWA28C2311
23 P.S.CORD W/OUT PLUG 1 CWA20C2590 ←←
24 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2986 CWA73C2983 CWA73C2995
25 ELECTRONIC CONTROLLER - POWER 1 CWA744527W ←←
26 SENSOR COMPLETE 1 CWA50C2122 CWA50C2401 ←
27 CONTROL BOARD FRONT COVER 1 CWH131207 ←←
28 INDICATOR COMPLETE 1 CWE39C1183 ←←
29 INDICATOR HOLDER 1 CWD932744 ←←
30 INDICATOR HOLDER 1 CWD932745 ←←
31 CONTROL BOARD FRONT COVER 1 CWH13C1171 ←←
32 REMOTE CONTROL COMPLETE 1 CWA75C3169 ←←
33 FRONT GRILLE COMPLETE 1 CWE11C3911 ←←
34 INTAKE GRILLE COMPLETE 1 CWE22C1409 ←←
35 GRILLE DOOR COMPLETE 1 CWE14C1010 ←←
36 E-ION FILTER 2 CWD00K1004 ←←
37 SCREW - FRONT GRILLE 2 XTT4+16CFJ ←←
38 CAP - FRONT GRILLE 2 CWH521109 ←←
39 DRAIN HOSE 1 CWH851063 ←←
40 INSTALLATION PLATE 1 CWH361067 ←←
41 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ←←
42 FULCRUM 1 CWH621049 ←←
