64
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
[PHAAM] Printed in Malaysia
SSTK0712-00
REF. NO. PART NAME & DESCRIPTION QTY. CU-C7HKD CU-C9HKD CU-C12HKD REMARKS
1 CHASSY ASS’Y 1 CWD50K2107 ←←
2 SOUND PROOF MATERIAL 1 CWG302254 ← CWG302422
3 FAN MOTOR BRACKET 1 CWD541069 ← CWD541074
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ←←
5 FAN MOTOR 1 CWA951378J CWA951534 ← 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406J ←←
7 PROPELLER FAN ASS’Y 1 CWH03K1020 ←←
8 NUT - PROPELLER FAN 1 CWH56053J ←←
9 COMPRESSOR 1 2RS122D5BG02 2PS156D3DA02 2PS206D3CB02 0
10 ANTI - VIBRATION BUSHING 3 CWH50077 ←←
11 NUT - COMPRESSOR MOUNT 3 CWH56000J ←←
12 CONDENSER 1 CWB32C2413 CWB32C2412 CWB32C2370
13 CAPILLARY TUBE ASS’Y 1 CWB15K1141 CWB15K1178 CWB15K1202
14 STRAINER 1 CWB11025 ←←
15 HOLDER COUPLING 1 CWH351047 ←←
16 2-WAY VALVE (LIQUID) 1 CWB021217 ←←0
17 3-WAY VALVE (GAS) 1 CWB011257 ← CWB011488 0
18 OVERLOAD PROTECTOR 1 CWA121050J CWA121091J CWA121251
19 HOLDER - O.L.P. 1 CWH7041200 ←←
20 TERMINAL COVER 1 CWH171011 ←←
21 NUT - TERMINAL COVER 1 CWH7080300J ←←
22 SOUND PROOF BOARD 1 CWH151074 ←←0
23 TERMINAL BOARD ASS’Y 1 CWA28K1064J ←←
24 CAPACITOR - COM. (20μF, 370V)
(30μF, 400V)
1 DS371206CPNA FOGAH306A004 ← 0
25 HOLDER CAPACITOR 1 CWH301038 CWH301035 ←
26 CAPACITOR - F.M (2.0μF, 440V) 1 DS441205NPQA ←←
27 CABINET SIDE PLATE 1 CWE041110A ←←
28 CABINET SIDE PLATE COMPLETE 1 CWE04C1042 ←←
29 CABINET FRONT PLATE ASS’Y 1 CWE06K1048 ← CWE06K1057
30 CABINET TOP PLATE 1 CWE031041A ←←
31 CONTROL BOARD COVER COMP 1 CWH13C1099 ←←
32 WIRE NET 1 CWD041057A ←←
33 OPERATION INSTRUCTIONS 1 CWF565767 ←←
34 INSTALLATION INSTRUCTIONS 1 CWF613305 ←←
35 INSTALLATION INSTRUCTIONS 1 CWF613306 ←←
