8.3 CS-C24MKP-7 CU-C24MKP-7
Resistance of Outdoor Fan Motor Windings Resistance of Compressor Windings
MODEL CU-C24MKP-7 MODEL CU-C24MKP-7
CONNECTION CWA951383J CONNECTION 2JS438D3CB04
BLUE-YELLOW 116 C-R 1.121
YELLOW-ORANGE 136 C-S 2.535
YELLOW-RED 103 Note: Resistance at 20°C of ambient temperature.
Note: Resistance at 25°C of ambient temperature.
