12.15.9 ECO NAVI and AUTO COMF Demo Mode
To enable ECO DEMO mode:
To disable ECO Demo MODE:
o Transmit ECO Demo signal again.
o Transmit Patrol Demo signal.
Operation details
Infrared sensor Human Activity Sensor
Sensor 1 Sensor 2 Left Center Right
Vane position Fan speed
1 0 5 HI
1 1 Auto Swing HI
0 1 1 HI
0 0 Auto Swing LO
The target area will maintain for 5 seconds before changeover to next detection.
If no activity detection, the last action will maintain for 30 seconds before changeover to human absence status.
