95
REF.
NO.
PART NAME & DESCRIPTION QTY CU-C7MKP-7 CU-C9MKP-7 CU-C12MKP-7 REMARK
1 CHASSIS ASS’Y 1 CWD50K2107  
2 SOUND PROOF MATERIAL 1 CWG302254  -
3 FAN MOTOR BRACKET 1 CWD541069  CWD541074
4 SCREW - FAN MOTOR BRACKET 2 CWH551217  
5 FAN MOTOR 1 CWA951673 CWA951691  O
6 SCREW - FAN MOTOR MOUNT 3 CWH55252J CWH55406J 
7 PROPELLER FAN ASS’Y 1 CWH03K1020  
8 NUT - PROPELLER FAN 1 CWH56053J  
9 COMPRESSOR (50HZ, 220/240V) 1 2RS122D5AD02 2PS146D3BA06 2PS206D3CA06 O
10 ANTI - VIBRATION BUSHING 3 CWH50077  
11 NUT - COMPRESSOR MOUNT 3 CWH56000J  
12 CONDENSER 1 CWB32C2801 CWB32C2800 CWB32C2828
13 CAPILLARY TUBE ASS’Y 1 CWB15K1268 CWB15K1267 CWB15K1269
14 STRAINER 1 CWB11025  
15 HOLDER COUPLING 1 CWH351047  
16 2-WAY VALVE (LIQUID) 1 CWB021217   O
17 3-WAY VALVE (GAS) 1 CWB011257  CWB011488 O
18 OVERLOAD PROTECTOR WITH WIRE 1 CWA67C8787 CWA67C9851 CWA67C7545
19 HOLDER - O.L.P. 1 CWH7041200  
20 TERMINAL COVER 1 CWH171011  
21 NUT - TERMINAL COVER 1 CWH7080300J  
22 SOUND PROOF BOARD 1 CWH151074  
23 TERMINAL BOARD ASS’Y 1 CWA28K1064J  
24 CAPACITOR - COM. 1 DS441156CPNA F0GAH306A004  O
25 HOLDER CAPACITOR 1 CWH301038 CWH301035 
26 CAPACITOR - F.M 1 DS441205NPQA   O
27 CABINET SIDE PLATE 1 CWE041205A  
28 CABINET SIDE PLATE COMPLETE 1 CWE04C1114 CWE04C1203 CWE04C1115
29 CABINET FRONT PLATE ASS’Y 1 CWE06K1048  CWE06K1057
30 CABINET TOP PLATE 1 CWE031041A  
31 CONTROL BOARD COVER COMP 1 CWH13C1099  
(Note)
 All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
 “O” marked parts are recommended to be kept in stock.
