99
REF.
NO.
PART NAME & DESCRIPTION QTY CU-C24MKP-7 REMARK
1 CHASSIS ASS’Y 1 CWD50K2100
3 FAN MOTOR BRACKET 1 CWD541065
4 SCREW - FAN MOTOR BRACKET 2 CWH551217
5 FAN MOTOR 1 CWA951383J O
6 SCREW - FAN MOTOR MOUNT 3 CWH55252J
7 PROPELLER FAN ASS’Y 1 CWH03K1017
8 NUT - PROPELLER FAN 1 CWH561038J
9 COMPRESSOR 1 2JS438D3CB04 O
10 PACKING 3 CWB81043
11 ANTI - VIBRATION BUSHING 3 CWH50055
12 NUT - COMPRESSOR MOUNT 3 CWH561049
13 CONDENSER 1 CWB32C2592
14 CAPILLARY TUBE ASS’Y 1 CWB15K1311
15 STRAINER 1 CWB11025
16 HOLDER COUPLING 1 CWH351036
17 2-WAY VALVE (LIQUID) 1 CWB021175 O
18 3-WAY VALVE (GAS) 1 CWB011484 O
21 TERMINAL COVER 1 CWH171012
22 NUT - TERMINAL COVER 1 CWH7080300J
23 SOUND PROOF BOARD 1 CWH151051
24 TERMINAL BOARD ASS’Y 1 CWA28K1064J O
26 CAPACITOR - COM. 1 CWA312079 O
27 HOLDER CAPACITOR 1 CWH30060
28 CAPACITOR - F.M 1 DS441355NPQA O
29 CABINET SIDE PLATE 1 CWE041254A
30 CABINET SIDE PLATE COMPLETE 1 CWE04C1128
31 CABINET FRONT PLATE ASS’Y 1 CWE06K1043
32 CABINET TOP PLATE 1 CWE03K1009A
33 CONTROL BOARD COVER COMP 1 CWH131168
34 HANDLE 1 CWE161010
35 CONTROL BOARD COVER (RIGHT-TOP) 1 CWH131169A
36 HANDLE 2 CWE16000E
37 THERMOSTAT 1 CWA151061
43 SOUND PROOF MATERIAL 1 CWG302407
(Note)
All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
“O” marked parts are recommended to be kept in stock.
Printed in Malaysia
FY1106-0
