83
(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CS-CE9LKE CS-CE12LKE REMARKS
1 CHASSY COMPLETE 1 CWD50C1653 ←
2 FAN MOTOR 1 ARW6101CB ← O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1076 ←
4 BEARING ASS’Y 1 CWH64K007 ←
5 SCREW - CROSS FLOW FAN 1 CWH551146 ←
6 EVAPORATOR CO. 1 CWB30C3097 CWB30C3324
7 FLARE NUT (LIQUID) 1 CWT251030 ←
8 FLARE NUT (GAS) 1 CWT251031 ←
9 CLIP FOR SENSOR 1 CWH32143 ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C3084 ←
11 VERTICAL VANE 11 CWE241287 ←
12 CONNECTING BAR 1 CWE261152 ←
13 CONNECTING BAR 1 CWE261153 ←
14 CONNECTING BAR 1 CWE261154 ←
15 CONNECTING BAR 1 CWE261155 ←
16 FULCRUM 1 CWH621102 ←
17 AIR SWING MOTOR 1 CWA981240 ← O
18 CAP - DRAIN TRAY 1 CWH521096 ←
19 HORIZONTAL VANE COMPLETE 1 CWE24C1268 ←
20 BACK COVER CHASSIS 1 CWD933233 ←
21 CONTROL BOARD CASING 1 CWH102370 ←
22 TERMINAL BOARD COMPLETE 1 CWA28C2357 ← O
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C4811 CWA73C4812 O
24 ELECTRONIC CONTROLLER - POWER 1 CWA745837 ← O
25 ELECTRONIC CONTROLLER - INDICATOR & RECEIVER 1 CWA745997 ← O
26 INDICATOR HOLDER 1 CWD933021 ←
27 SENSOR COMPLETE 1 CWA50C2401 ← O
28 CONTROL BOARD FRONT COVER 1 CWH13C1183 ←
29 CONTROL BOARD TOP COVER 1 CWH131350 ←
31 REMOTE CONTROL COMPLETE 1 CWA75C3632 ← O
32 FRONT GRILLE COMPLETE 1 CWE11C4580 ← O
33 INTAKE GRILLE COMPLETE 1 CWE22C1508 ←
34 GRILLE DOOR COMPLETE 1 CWE14C1029 ←
35 AIR FILTER 2 CWD001279 ←
36 SCREW - FRONT GRILLE 2 XTT4+16CFJ ←
37 CAP - FRONT GRILLE 2 CWH521194 ←
38 DRAIN HOSE 1 CWH851173 ←
39 INSTALLATION PLATE 1 CWH361097 ←
40 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
45 OPERATING INSTRUCTIONS 1 CWF567551 ←
46 INSTALLATION INSTRUCTIONS 1 CWF614502 ←
47 INSTALLATION INSTRUCTIONS 1 CWF614503 ←
48 INSTALLATION INSTRUCTIONS 1 CWF614504 ←
49 INSTALLATION INSTRUCTIONS 1 CWF614505 ←
50 INSTALLATION INSTRUCTIONS 1 CWF614506 ←
