106
14 Replacement Part List (Indoor Unit)
NO. PART DESCRIPTION QTY. CS-D34DTQ CS-D43DTQ CS-D50DTQ
1 CABINET TOP PLATE 1 CWE001016 ←←
2 CABINET FRONT PLATE 1 CWG07K1008 ←←
3 CABINET SIDE PLATE (L) 1 CWD63K1003 ←←
4 VANE SUPPORTER (L) 1 CWG071144 ←←
5 CATCHER 1 CWH601005 ←←
6 CABINET SIDE PLATE (R) 1 CWD63K1004 ←←
7 VANE SUPPORTER (R) 1 CWG071145 ←←
8 BLOWER WHEEL BASE ASS’Y 1 CWD90K1008 ←←
9 BRACKET FAN MOTOR ASS’Y 1 CWD54K1004 CWD54K1005 ←
10 FAN SHAFT 1 CWH631031 ←←
11 COUPLING SHAFT COMPLETE 1 CWH08C1001 ←←
12 SCREW-COUPLING SHAFT COMPLETE 2 CWH55424 ←←
13 BEARING 1 CWH64C1001 ←←
14 BEARING COVER 1 CWD911196 ←←
15 AIR GUIDER B. WHEEL (TOP) 4 CWD321032 ←←
16 AIR GUIDER B. WHEEL (BOTTOM) 4 CWD321033 ←←
17 BLOWER WHEEL 3 CWH011005 ←←
18 BLOWER WHEEL 1 CWH011010 ←←
19 FAN MOTOR AC 40W SINGLE 1 CWA921054J CWA921055J ←
20 FAN MOTOR SUPPORTER 2 CWD93C1027 ←←
21 SIDE FILTER SEAL 1 CWD911158 ←←
22 SEPARATOR 1 CWD911113 ←←
23 EVAPORATOR COMPLETE 1 CWB30C16192 CWB30C1623 ←
24 TUBE ASS’Y (CAPIL. TUBE-EVA) 1 CWT07K1268 CWT07K1270 ←
25 FLARE NUT (3/8”) 1 CWT251031 ←←
26 FLARE NUT (5/8”) 1 CWT251037 ←←
27 HEATPROOF TUBE 1 CWG021024 ←←
28 HEATPROOF TUBE 1 CWG021027 ←←
29 WATERPROOF COVER 1 CWG251007 ←←
30 SENSOR-EVAPORATOR 1 CWA50C2232 ←←
31 VANE COMPLETE 1 CWE24C1024 ←←
32 VANE SIDE HOLDER 1 CWH511027 ←←
33 BEARING 1 CWH641004 ←←
34 FULCRUM 2 CWH621008A ←←
35 VERTICAL VANE HOLDER (MANUAL) 4 CWD911107 ←←
36 VERTICAL VANE (HORIZ.AIR FLOW) 16 CWE241051 ←←
37 CONNECTING BAR 8 CWE261019 ←←
38 AIR SWING MOTOR COMPLETE 1 CWA98C1004 ←←
39 CONTROL BOARD ASS’Y 1 CWH10K1050 ←←
40 TERMINAL BOARD 1 CWA281031J ←←
41 CAPACITOR-FAN MOTOR (MF/V) 1 DS451405BPQC DS461455QP-A DS441605BPQL
42 ELECTRONIC CONTROLLER-MAIN 1 CWA73C1750 CWA73C1751 CWA73C1752
43 CONTROL BOARD COVER-COMPLETE 1 CWH13C1106 ←←
44 LOCKING GUARD SPACER 6 CWH541026 ←←
45 TRANSFORMER 1 CWA40C1031 ←←
46 SENSOR COMPLETE 2 CWA50C2233 ←←
47 CABLE CLIP (CORD CLAMPER) 1 CWH88133 ←←
48 HOLDER SENSOR 1 CWH32137 ←←
49 WIRE SADDLE 4 CWH881016 ←←
50 DRAIN PAN ASS’Y 1 CWH40K1013 ←←
51 DRAIN PLUG 1 CWB821002 ←←
52 CABINET BOTTOM PLATE 1 CWE051001A
←←
53 CURVED WIRE 1 CWH751002 ←←
54 RAY RECEIVER HOLDER 1 CWD911428 ←←
55 INTAKE GRILLE (LARGE) 2 CWE221029 ←←
56 INTAKE GRILLE (SMALL) 1 CWE221030 ←←
57 GRILLE SLIDE HOOK 6 CWH891001 ←←
58 AIR FILTER (MAIN) 2 CWD001169 ←←
59 AIR FILTER (MIDDLE) 1 CWD001042 ←←
60 AIR FILTER (SIDE VERTICAL) 1 CWD001041 ←←
61 BRACKET HANGER (R) 1 CWD601014 ←←
62 BRACKET HANGER (L) 1 CWD601015 ←←
63 CABINET SIDE COVER (R) 1 CWE041024 ←←
To Next Page
