12
3.4. CS-D43DTQ CU-D43DBQ7 (60Hz)
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ELECTRICAL DATA (60 Hz)
Indoor Unit Outdoor Unit
ITEM / MODEL Main Body CS-D43DTQ CU-D43DBQ7
Remote CZ-RD513C (Wired)
Control CZ-RL013T (Wireless)
Cooling Capacity kW 13.50
BTU/h 46,100
Refrigerant Charges-less m 30
Standard Air Volume for High,
m
3
/min
Hi 30.0 Me 26.8 Lo 23.1 103.0
Medium and Low Speed cfm 1059 946 815 3637
Outside Dimension (H × W × D) mm 250 × 1600 × 700 1170 × 900 × 320
inch 9-27/32 × 62-31/32 × 27-9/16 46-1/16 × 35-7/16 × 12-19/32
Net Weight kg (lbs) 47 (104) 83 (182)
Piping Refrigerant Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Connection Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain O.D Ø 20 I.D Ø 20 × 1
Compressor Type, Number of Set — Hermetic, 1
Starting Method — Permanent Split Capacitor
Motor Type — 2-pole 1 phase brushless motor
Rated Output kW — 3.75
Fan Type, Number of Set Sirocco fan-1 Propeller fan-1
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.12 0.07 × 2
Air-heat Exchanger (Row × Stage × FPI) Louver-fin type (3 × 18 × 14) Corrugate-fin type (1 × 44 × 21)
Refrigerant Control — Expansion Valve
Refrigerant Oil (Charged)
cm
3
— 1400
Refrigerant (Charged) R22 kg (oz) — 2.20 (81.1)
Running Control Switch Wireless or Wired Remote Control —
Adjustment Room Temperature Thermostat —
Safety Devices Internal protector for compressor
Noise Level dB (A) Hi 47 Lo 43 Hi 56
Power Level
dB
64/60 69/-
Moisture Removal L/h (Pt/h) 8.6 (18.1)
EER W/W 2.39
ITEM / MODEL Condition by ISO5151
Volts V 220
Phase Three
Running Current A 16.7
Starting Current A 120
Power Factor % 89
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power Source AC, 3 ~ 220V, 60Hz
