16 Replacement Part List (Outdoor Unit)
16.1. CU-D34DBQ7 CU-D43DBQ7 CU-D50DBQ7
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
REF. NO. PART DESCRIPTION QTY. CU-D34DBQ7 CU-D43DBQ7 CU-D50DBQ7
1 BASE PAN ASS’Y 1 CWD52K1103 ←←
2 COMPRESSOR DC 280V 1 JT125GA JT160GA JT170GA
3 ANTI-VIBRATION BUSHING 3 CWH501081 ←←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ←←
5 CONDENSER COMPLETE 1 CWB32C1790 ←←
6 TUBE ASS’Y (EXP.VALVE AND STRAINER) 1 CWT023540 CWT023741 ←
7 RECEIVER 1 CWB141021 ←←
8 PIPE HOLDER RUBBER 1 CWG251022 ←←
9 TUBE ASS’Y (PRESSURE SWITCH) 1 CWT023519 ← CWT024183
10 HIGH PRESSURE SWITCH 1 CWA101012 ←←
11 3-WAYS VALVE (GAS) 1 CWB011295 ←←
12 3-WAYS VALVE (LIQUID) 1 CWB011299 ←←
13 HOLDER-SERVICE VALVE 1 CWD911425 ←←
14 SOUND-PROOF BOARD 1 CWH151079 ←←
15 SOUND PROOF MATERIAL 1 CWG302311 ←←
16 SOUND PROOF MATERIAL 1 CWG302360 ←←
17 V-COIL COMPLETE 1 CWA43C2203 ←←
18 PIPE SENSOR (DISCHARGE) 1 CWA50C2293 ←←
19 PIPE SENSOR (COIL) 1 CWA50C2294 ←←
20 SPRING FOR SENSOR 2 CWH711010 ←←
21 CABINET REAR PLATE COMPLETE 1 CWE02C1026 ←←
22 CONTROL BOARD ASS’Y 1 CWH10K1064 ←←
23 TERMINAL BOARD ASS’Y 1 CWA28K1158 ←←
24 TERMINAL BOARD ASS’Y 1 CWA28K1076J ←←
25 CAPACITOR-FAN MOTOR 2 DS461305QP-A ←←
26 ELECTRONIC MAGNETIC SWITCH 1 K6C4E8A00001 K6C5E8A00001 ←
27 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1859 CWA73C1860 CWA73C1861
28 TRANSFORMER 1 CWA401060 ←←
29 BRACKET FAN MOTOR ASS’Y 1 CWD54K1019 ←←
30 SCREW-BRACKET FAN MOTOR 2 CWH551040J ←←
31 FAN MOTOR 1 CWA951516 ←←
32 FAN MOTOR 1 CWA951509 ←←
33 SCREW-FAN MOTOR 8 CWH551040J ←←
34 PROPELLER FAN 2 CWH30K1017 ←←
35 NUT for PROPELLER FAN 2 CWH561038J ←←
36 CABINET TOP PLATE COMPLETE 1 CWE03C1039 ←←
37 PIPE COVER (FRONT) 1 CWD601074A ←←
38 PIPE COVER (BACK) 1 CWD60K1003A ←←
39 CABINET FRONT PLATE 1 CWE061092A ←←
40 DISCHARGE GRILLE 2 CWE201075 ←←
41 CABINET SIDE PLATE ASS’Y 1 CWE04K1022A ←←
42 WIRE NET 1 CWD041064A ←←
43 CABINET FRONT PLATE COMPLETE 1 CWE06C1132 ←←
44 HANDLE 2 CWE161008 ←←
45 LEADWIRE-COMPRESSOR 1 CWA67C6239 CWA67C6250 ←
46 ACCESSORY COMPLETE 1 CWH82C1105 ←←
47 INSTALLATION INSTRUCTION 1 CWF613013 ←←
