Panasonic CS-E12NKEW Service Manual

8
Indoor CS-E12NKEW, CS-XE12NKEW CS-E15NKEW, CS-XE15NKEW
Model
Outdoor CU-E12NKE CU-E15NKE
Performance Test Condition EUROVENT EUROVENT
Phase, Hz Single, 50 Single, 50
Power Supply
V 230 230
Min. Mid. Max. Min. Mid. Max.
kW 0.85 3.50 4.00 0.85 4.20 5.00
BTU/h 2900 11900 13600 2900 14300 17100
Capacity
Kcal/h 730 3010 3440 730 3610 4300
Running Current A - 4.0 - - 5.7 -
Input Power W 250 855 1.13k 260 1.26k 1.57k
Annual Consumption kWh - 428 - - 630 -
W/W 3.40 4.09 3.54 3.27 3.33 3.18
BTU/hW 11.60 13.92 12.04 11.15 11.35 10.89
EER
Kcal/hW 2.92 3.52 3.04 2.81 2.87 2.74
Power Factor % - 93 - - 96 -
dB-A 42 / 28 / 20 43 / 31 / 25
Indoor Noise (H / L / QLo)
Power Level dB 58 / - 59 / -
dB-A 48 / - 49 / -
Cooling
Outdoor Noise (H / L)
Power Level dB 63 / - 64 / -
kW 0.85 4.00 6.00 0.85 5.30 6.80
BTU/h 2900 13600 20500 2900 18100 23200
Capacity
Kcal/h 730 3440 5160 730 4560 5850
Running Current A - 4.3 - - 6.6 -
Input Power W 245 930 1.71k 255 1.44k 1.94k
W/W 3.47 4.30 3.51 3.33 3.68 3.51
BTU/hW 11.84 14.62 11.99 11.37 12.57 11.96
COP
Kcal/hW 2.98 3.70 3.02 2.86 3.17 3.02
Power Factor % - 94 - - 95 -
dB-A 42 / 33 / 20 43 / 35 / 29
Indoor Noise (H / L / QLo)
Power Level dB 58 / - 59 / -
dB-A 50 / - 51 / -
Heating
Outdoor Noise (H / L)
Power Level dB 65 / - 66 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 4.47 / 1.48k / 3.02 4.92 / 1.72k / 2.86
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.37 / 1.49k / 2.26 4.11 / 1.73k / 2.38
Max Current (A) / Max Input Power (W) 7.8 / 1.71k 9.0 / 1.94k
Starting Current (A) 4.3 6.6
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (6-poles) Brushless (6-poles)
Compressor
Output Power W 700 700

Panasonic CS-E12NKEW Specifications

General

Type	Air conditioner indoor unit
Built-in display	No
Remotely operated	Yes
Cooling capacity (max)	- BTU/h
Air conditioner functions	cooling, heating
Cooling capacity in watts (max)	3500 W
Heating capacity in watts (max)	4400 W
Cooling energy efficiency (EER, W/W)	3.87
Heating energy efficiency (COP, W/W)	4.04
Indoor unit type	Wall-mountable
Indoor units quantity	1
Outdoor units quantity	0
Noise level (low speed)	20 dB
Noise level (high speed)	42 dB
Noise level (medium speed)	28 dB
Power requirements	AC 230 V

Weight and Dimensions

Dimensions (WxDxH)	870 x 214 x 290 mm
