Panasonic CS-E15GKEW Service Manual

4
2 Specifications
2.1. CS-E15GKEW CU-E15GKE-1
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity
kW 4.30 (0.80 ~ 5.00)
kCal/h 3700 (690 ~ 4300)
EER
W/W 3.21 (4.10 ~ 3.13)
kCal/hW 2.76 (3.54 ~ 2.69)
Noise Level
dB (A) High 43, Low 31 High 49
Power level dB 54 62
H
E
A
T
I
N
G
Capacity
kW 5.30 (0.80 ~ 6.80)
kCal/h 4560 (690 ~ 5850)
COP
W/W 3.51 (4.32 ~ 3.49)
kCal/hW 3.02 (3.73 ~ 3.00)
Noise Level
dB (A) High 43, Low 35 High 51
Power level dB 54 64
Moisture Removal
l/h 2.4
pt/h 5.1
Air Volume
Lo
m
3
/min (ft
3
/min)
Cooling; 7.9 (280)
—
Heating; 9.6 (340)
Me
m
3
/min (ft
3
/min)
Cooling; 9.8 (350)
—
Heating; 11.5 (410)
Hi
m
3
/min (ft
3
/min)
Cooling; 11.7 (410)
Cooling; 31.4 (1110)
Heating; 12.1 (430)
SHi
m
3
/min (ft
3
/min)
Cooling; 12.4 (440)
—
Heating; 12.2 (430)
Refrigeration Control Device — Check Valve & Capillary Tube
Refrigeration Oil
cm
3
— RB68A or Freol Alpha68M (320)
Refrigerant (R410A) g (oz) — 1050 (37.1)
Dimension
Height mm (inch) 280 (11-1/32) 540 (21-1/4)
Width mm (inch) 799 (31-15/32) 780 (30-23/32)
Depth mm (inch) 183 (7-7/32) 289 (11-3/8)
Net Weight kg (lbs) 9 (20) 35 (77)
Pipe Diameter
Gas mm (inch) 12.7 (1/2)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Height Difference m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 12 —
Length mm 650 —
Compressor
Type — Hermetic Motor
Motor Type — Brushless (6-pole)
Rated Output W — 700
Fan
Type Cross-Flow Fan Propeller Fan
Material ASG20K1 PP
Motor Type Transistor (8-pole) Induction (6-pole)
Input Power W — 70
Output Power W 30 30
Fan Speed
Lo (Cool/Heat) rpm 1010 / 1230 —
Me (Cool/Heat) rpm 1255 / 1470 —
Hi (Cool/Heat) rpm 1500 / 1550 850 / —
SHi (Cool/Heat) rpm 1590 / 1570 —
